COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-07397		Well Classification: GW Status: PR - 6/26/2000
Well Name/No:COUEY #17-2
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date6/26/2000
FacilityID:89067LocationID:334792
County:GARFIELD #045Location:NENW 17 7S92W 6
Field:MAMM CREEK - #52500Elevation:6086 ft.
Basin:PICEANCE BASIN
Planned Location:889FNL  2368 FWLLat/Long: 39.451211 / -107.691013Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.451740 / -107.690990Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 6/26/2000             Measured TD: 6103 ft.    Vertical TD: 5978 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 6/26/2000
Wellbore PermitDIRECTIONAL
Permit #:990411 Expiration Date:6/15/2000
Proposed Top PZ Location:Sec: Twp: Footage: 647 FNL  2046 FEL
Bottom Hole Location:Sec: Twp: Footage: 656 FNL  2004 FEL
Proposed Depth/Form:
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:Not available
Unit: Unit Number:
Wellbore Completed
Completion Date:8/23/1999
Spud Date:8/5/1999Spud Date Is:ACTUAL
Measured TD:6103 ft.Measured PB depth:6058 ft.
True Vertical TD:5978 ft.True Vertical PB depth:6930 ft.
Top PZ Location:Sec: Twp: Footage: 647 FNL  2046 FEL
Bottom Hole Location:Sec: Twp: Footage: 656 FNL  2004 FEL
Log Types:DUAL IND, NEU DENS.
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1194 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 550, Top: 0 ft., Bottom: 1194 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 6301 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 1100, Top: 1100 ft., Bottom: 6301 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WILLIAMS FORK2698 ft.5750 ft.NN
COAL5750 ft.NN

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 6/26/2000                 Interval Top: 4281 ft.    Interval Bottom: 5500 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:9/30/1999Choke Size:1.125 in.
Formation Name:WILLIAMS FORKCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:8/23/1999
Treatment Summary:CM PR FRO INITIAL 2ND & 3RD COMPLETION INTERVALS & 4TH COMPLETION.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:5/14/2000Test Method:FLOWING
Hours Tested:24Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 3
BBLS_OIL 10
BTU_GAS 1150
CALC_BBLS_H2O 3
CALC_BBLS_OIL 10
CALC_MCF_GAS 1079
CASING_PRESS 1125
MCF_GAS 1079
TUBING_PRESS 1025
Perforation Data:
Interval Top:4281 ft.# Of Holes:30
Interval Bottom:5500 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)6
Total Gas Produced (MCF)12758
GOR2126333
GOR DeterminationMCFE
Average BOE per Day6.041
Average MCFE per Day35.050

 Federal Financial Assurance  i Y

 Tribal Well  i No
