| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/3/2019 Measured TD: 14743 ft. Vertical TD: 6908 ft. | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 1/17/2019 | | Proposed Top PZ Location: | Sec:26 Twp: 5N 65W | Footage: 180 FSL 2635 FEL | | Bottom Hole Location: | Sec:27 Twp: 5N 65W | Footage: 120 FSL 502 FWL | | Prop Depth/Form: | 15106 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 560, Drill Unit: GW | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1600 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 920, Top: 0 ft., Bottom: 1600 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 15106 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2035, Top: 0 ft., Bottom: 15106 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/24/2018 | | Spud Date: | 2/17/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 14743 ft. | Measured PB depth: | 14726 ft. | | True Vertical TD: | 6908 ft. | True Vertical PB depth: | 6908 ft. | | Top PZ Location: | Sec:26 Twp: 5N 65W | Footage: 180 FSL 2635 FEL | | Bottom Hole Location: | Sec:27 Twp: 5N 65W | Footage: 120 FSL 502 FWL | | Log Types: | CBL, MWD, (DIL in 123-16715 & 123-30703) | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1627 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 750, Top: 0 ft., Bottom: 1627 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 14741 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 1565, Top: 2595 ft., Bottom: 14743 ft., Determination Method: CBL |
| | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3653 ft. | | | | | SUSSEX | 4320 ft. | | | | | SHARON SPRINGS | 6587 ft. | | | | | NIOBRARA | 6733 ft. | | | |
| | Completed Information for Formation NIOBRARA Formation Classification: OW Status: PR - 4/3/2019 |
| | 1st Production Date: | 3/29/2019 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No | | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 2/7/2019 | Treatment End Date: | 2/20/2019 | | Treatment Summary: | 42 Stage Plug and Perf
Total Fluid: 149,539 bbls
Gel Fluid: 114,716 bbls
Slickwater Fluid: 33,643 bbls
15% HCl Acid: 1,180 bbls
Total Proppant: 7,573,900 lbs
Silica Proppant: 7,573,900 lbs
Method for determining flowback: measuring flowback tank volumes. | | Total fluid used in treatment (bbls): | 149539 | Max pressure during treatment (psi): | 4689 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 42 | | Total acid used in treatment (bbls): | 1180 | Min frac gradient (psi/ft): | 0.95 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 2541 | | Fresh water used in treatment (bbls): | 148359 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 7573900 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6937 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | |
| | Initial Test Data: | | Test Date: | 4/3/2019 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD |
| | Test Type | Measure |
|---|
| BBLS_H2O | 135 | | BBLS_OIL | 291 | | BTU_GAS | 1310 | | CALC_BBLS_H2O | 135 | | CALC_BBLS_OIL | 291 | | CALC_GOR | 4021 | | CALC_MCF_GAS | 1170 | | CASING_PRESS | 3092 | | GRAVITY_OIL | 57 | | MCF_GAS | 1170 | | TUBING_PRESS | 2296 |
| | Perforation Data: | | Interval Top: | 7316 ft. | # Of Holes: | 1482 | | Interval Bottom: | 14741 ft. | Hole Size: | 0.42 in. |
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 9066 |
| Total Gas Produced (MCF) | 167229 |
| GOR | 18445 |
| GOR Determination | MCFE |
| Average BOE per Day | 103.658 |
| Average MCFE per Day | 601.195 |
| Federal Financial Assurance | i | |
|
|
