COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISOld GIS Map Old GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-50071		Well Classification: OW Status: PA - 8/30/2021
Well Name/No:SARCHET #21-3HZ
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:KERR MCGEE OIL & GAS ONSHORE LP - 47120
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date8/30/2021
FacilityID:463772LocationID:463773
County:WELD #123Location:SWSW 21 3N66W 6
Field:WATTENBERG - #90750Elevation:4983 ft.
Basin:DENVER (DJ) BASIN
Planned Location:610FSL  340 FWLLat/Long: 40.204826 / -104.790393Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.204826 / -104.790393Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PA - 8/30/2021             Measured TD: 12993 ft.    Vertical TD: 7206 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PA - 8/30/2021
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:4/3/2021
Proposed Top PZ Location:Sec:21 Twp: 3N 66W Footage: 78 FSL  926 FWL
Bottom Hole Location:Sec:28 Twp: 3N 66W Footage: 50 FSL  921 FWL
Proposed Depth/Form:12945 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 480, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 36.94 , Citings Type: PLANNED
Cement:Sacks: 64, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 590, Top: 0 ft., Bottom: 1500 ft.
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 12935 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 1516, Top: , Bottom: 12935 ft.
Wellbore Completed
Completion Date:9/10/2019
Spud Date:7/3/2019Spud Date Is:ACTUAL
Measured TD:12993 ft.Measured PB depth:12974 ft.
True Vertical TD:7206 ft.True Vertical PB depth:7206 ft.
Bottom Hole Location:Sec:28 Twp: 3N 66WFootage: 50 FSL  924 FWL
Log Types:CBL, MWD/LWD. (GR/CNL in API 123-50074).
Casing:String Type: CONDUCTOR, Hole Size: , Size: , Top: 0 ft., Depth: 100 ft., Weight: N42 , Citings Type: ACTUAL
Cement:Sacks: 64, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1852 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 693, Top: 0 ft., Bottom: 1852 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 12983 ft., Weight: 17 , Citings Type: ACTUAL
Cement:Sacks: 803, Top: 2027 ft., Bottom: 12983 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
FOX HILLS1132 ft.
PARKMAN4293 ft.
SUSSEX4441 ft.
SHARON SPRINGS7268 ft.
NIOBRARA7407 ft.
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY08/30/2021
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
December 2024 - November 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
