Wellbore #00 Wellbore Classification: OW Status: PR - 2/28/2021 Measured TD: 19242 ft. Vertical TD: 7653 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/28/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/20/2020 | | Proposed Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 460 FNL 2425 FWL | | Bottom Hole Location: | Sec:33 Twp: 2N 68W | Footage: 475 FSL 2444 FWL | | Proposed Depth/Form: | 19242 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: , Unit Acreage: 800, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 78, Top: 0 ft., Bottom: 98 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2168 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 840, Top: 0 ft., Bottom: 2168 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19242 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2760, Top: , Bottom: 19242 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/25/2020 | | Spud Date: | 9/4/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 19242 ft. | Measured PB depth: | 19215 ft. | | True Vertical TD: | 7653 ft. | True Vertical PB depth: | 7653 ft. | | Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 460 FNL 2425 FWL | | Bottom Hole Location: | Sec:33 Twp: 2N 68W | Footage: 475 FSL 2444 FWL | | Log Types: | MWD/LWD (IND in API 123-20125) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2216 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 883, Top: 0 ft., Bottom: 2216 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19229 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2425, Top: 1795 ft., Bottom: 19242 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4341 ft. | | N | N | | SHANNON | 4894 ft. | | N | N | | SHARON SPRINGS | 7242 ft. | | N | N | | NIOBRARA | 7348 ft. | | N | N | | FORT HAYS | 7809 ft. | | N | N | | CODELL | 7988 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: CM - 1/24/2022 Interval Top: 11841 ft. Interval Bottom: 13042 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/17/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/22/2020 | Treatment End Date: | 12/20/2020 | | Treatment Summary: | Niobrara: 11841-13042 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 11841 ft. | # Of Holes: | 884 | | Interval Bottom: | 13042 ft. | Hole Size: | 0.42 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 1/24/2022 Interval Top: 8463 ft. Interval Bottom: 16107 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | 3/17/2021 | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/22/2020 | Treatment End Date: | 12/20/2020 | | Treatment Summary: | Ft Hays: 8463-8665, 11640-11840, 13043-14014, 16078-16107 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 8463 ft. | # Of Holes: | 884 | | Interval Bottom: | 16107 ft. | Hole Size: | 0.42 in. |
|
Formation CODL Formation Classification: OW Status: CM - 1/24/2022 Interval Top: 8163 ft. Interval Bottom: 19097 ft.| Completed Information for Formation CODELL | | 1st Production Date: | 3/17/2021 | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/22/2020 | Treatment End Date: | 12/20/2020 | | Treatment Summary: | Codell: 8163-8414, 8666-11639, 14063-16077, 16156-19097 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 8163 ft. | # Of Holes: | 884 | | Interval Bottom: | 19097 ft. | Hole Size: | 0.42 in. |
|
Formation NBFHC Formation Classification: OW Status: PR - 2/28/2021 Interval Top: 8163 ft. Interval Bottom: 19097 ft.| Completed Information for Formation NIOBRARA-FT HAYS-CODELL | | 1st Production Date: | 3/17/2021 | Choke Size: | | | Formation Name: | NIOBRARA-FT HAYS-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/22/2020 | Treatment End Date: | 12/20/2020 | | Treatment Summary: | 243173 bbls of water, 97 bbls of additives (FRP-22G, Bardac 2250M, Bellacide 355, Dixichlor Max, SAFE-BFH-2, XLS-3Z, BHL-68W, ACI-97, ASF-67) and 36 bbl HCL in a 37 stage frac with 19848 lbs of DFR-1X, 652 lbs of PGA-4045, 6582125 lbs of silica quartz proppant
Oil and water are metered from flowback equipment. The daily water volumes are periodically checked against trucked volumes. All meters are calibrated before use on every pad. | | Total fluid used in treatment (bbls): | 243866 | Max pressure during treatment (psi): | 9318 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 37 | | Total acid used in treatment (bbls): | 36 | Min frac gradient (psi/ft): | 0.85 | | Recycled water used in treatment (bbls): | 560 | Total flowback volume recovered (bbls): | 13582 | | Fresh water used in treatment (bbls): | 243270 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6582125 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7645 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/28/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 392 | | BBLS_OIL | 679 | | BTU_GAS | 1270 | | CALC_BBLS_H2O | 392 | | CALC_BBLS_OIL | 679 | | CALC_GOR | 1607 | | CALC_MCF_GAS | 1091 | | CASING_PRESS | 2500 | | GRAVITY_OIL | 50 | | MCF_GAS | 1091 | | TUBING_PRESS | 1850 |
| | Perforation Data: | | Interval Top: | 8163 ft. | # Of Holes: | 884 | | Interval Bottom: | 19097 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 15010 |
| Total Gas Produced (MCF) | 293781 |
| GOR | 19572 |
| GOR Determination | MCFE |
| Average BOE per Day | 179.895 |
| Average MCFE per Day | 1043.368 |
| Federal Financial Assurance | i | |
|
|
