Wellbore #00 Wellbore Classification: OW Status: PR - 1/1/2021 Measured TD: 18594 ft. Vertical TD: 7084 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 1/1/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 12/10/2019 | | Proposed Top PZ Location: | Sec:11 Twp: 3N 68W | Footage: 1056 FSL 299 FWL | | Bottom Hole Location: | Sec:9 Twp: 3N 68W | Footage: 1134 FSL 415 FWL | | Proposed Depth/Form: | 18561 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 1440, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 624, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18561 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2386, Top: , Bottom: 18561 ft. |
| | |
| Wellbore Completed | | Completion Date: | 3/4/2018 | | Spud Date: | 1/7/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 18594 ft. | Measured PB depth: | 18586 ft. | | True Vertical TD: | 7084 ft. | True Vertical PB depth: | 7084 ft. | | Top PZ Location: | Sec:11 Twp: 3N 68W | Footage: 1056 FSL 299 FWL | | Bottom Hole Location: | Sec:9 Twp: 3N 68W | Footage: 1134 FSL 415 FWL | | Log Types: | CBL, Mud Log, MWD/LWD, (Triple Combo 123-39322) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1528 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 672, Top: 0 ft., Bottom: 1528 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18594 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 3180, Top: 2628 ft., Bottom: 18594 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3804 ft. | 4065 ft. | N | N | | SUSSEX | 4353 ft. | 4514 ft. | N | N | | SHANNON | 4943 ft. | 5049 ft. | N | N | | SHARON SPRINGS | 7585 ft. | | N | N | | NIOBRARA | 7792 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 1/1/2021 Interval Top: 8144 ft. Interval Bottom: 18504 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 6/30/2018 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 5/17/2018 | Treatment End Date: | 6/3/2018 | | Treatment Summary: | 935,443 lbs 100 Mesh Sand; 9,448,525 lbs 20/40 Sand; 2,255 bbls 15% HCL Acid; 232,282 bbls Gelled Fluid. Flowback determined from well test separator | | Total fluid used in treatment (bbls): | 234537 | Max pressure during treatment (psi): | 4761 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 69 | | Total acid used in treatment (bbls): | 2255 | Min frac gradient (psi/ft): | 0.93 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 15297 | | Fresh water used in treatment (bbls): | 232282 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 10383968 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7790 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 7/6/2018 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 514 | | BBLS_OIL | 400 | | BTU_GAS | 1272 | | CALC_BBLS_H2O | 514 | | CALC_BBLS_OIL | 400 | | CALC_GOR | 985 | | CALC_MCF_GAS | 394 | | CASING_PRESS | 2170 | | GRAVITY_OIL | 44 | | MCF_GAS | 394 | | TUBING_PRESS | 1678 |
| | Perforation Data: | | Interval Top: | 8144 ft. | # Of Holes: | 1794 | | Interval Bottom: | 18504 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 2731 |
| Total Gas Produced (MCF) | 89369 |
| GOR | 32723 |
| GOR Determination | MCFE |
| Average BOE per Day | 49.810 |
| Average MCFE per Day | 288.900 |
| Federal Financial Assurance | i | |
|
|
