Wellbore #00 Wellbore Classification: OW Status: PR - 11/18/2020 Measured TD: 17645 ft. Vertical TD: 7255 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 11/18/2020 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 5/25/2019 | | Proposed Top PZ Location: | Sec:35 Twp: 8N 67W | Footage: 659 FNL 650 FWL | | Bottom Hole Location: | Sec:2 Twp: 7N 67W | Footage: 650 FSL 650 FWL | | Proposed Depth/Form: | 17676 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 535-773 , Unit Acreage: 1280, Drill Unit: Sec 35 & Sec 2: All | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 80 ft., Weight: 92 , Citings Type: PLANNED | | Cement: | Sacks: 179, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 304, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17676 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2845, Top: 0 ft., Bottom: 17676 ft. |
| | |
| Wellbore Completed | | Completion Date: | 4/22/2018 | | Spud Date: | 3/28/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 17645 ft. | Measured PB depth: | 17614 ft. | | True Vertical TD: | 7255 ft. | True Vertical PB depth: | 7255 ft. | | Top PZ Location: | Sec:35 Twp: 8N 67W | Footage: 730 FNL 602 FWL | | Bottom Hole Location: | Sec:2 Twp: 7N 67W | Footage: 638 FSL 647 FWL | | Log Types: | MWD/LWD, CBL, Mud Log, (RES in API - 05-123-44921) | | Casing: | String Type: CONDUCTOR, Hole Size: 20 in., Size: 16 in., Top: 0 ft., Depth: 103 ft., Weight: 75 , Citings Type: ACTUAL | | Cement: | Sacks: 62, Top: 0 ft., Bottom: 103 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1620 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 556, Top: 0 ft., Bottom: 1620 ft., Determination Method: VISU | | Casing: | String Type: 1ST LINER, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17633 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 2436, Top: 1535 ft., Bottom: 17645 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | RICHARD | 3736 ft. | | N | N | | SUSSEX | 4390 ft. | | N | N | | HYGIENE | 5057 ft. | | N | N | | SHARON SPRINGS | 7488 ft. | | N | N | | NIOBRARA | 7540 ft. | | N | N | | FORT HAYS | 8093 ft. | | N | N | | CODELL | 8392 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 11/18/2020 Interval Top: 13641 ft. Interval Bottom: 13970 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 8/7/2018 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 6/30/2018 | Treatment End Date: | 7/14/2018 | | Treatment Summary: | Completed Interval: 13,641' - 13,970' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 13641 ft. | # Of Holes: | 70 | | Interval Bottom: | 13970 ft. | Hole Size: | 0.42 in. |
|
Formation CODL Formation Classification: OW Status: PR - 11/18/2020 Interval Top: 8400 ft. Interval Bottom: 17597 ft.| Completed Information for Formation CODELL | | 1st Production Date: | 8/7/2018 | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 6/30/2018 | Treatment End Date: | 7/14/2018 | | Treatment Summary: | Completed Interval : 8,400' - 11,483'; 11,670' - 11,971'; 12,063' - 13,358'; 14,004' - 15,662'; 15,919' - 16,068' - 16,207' - 17,597' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 8400 ft. | # Of Holes: | 1360 | | Interval Bottom: | 17597 ft. | Hole Size: | 0.42 in. |
|
Formation FTHYS Formation Classification: OW Status: PR - 11/18/2020 Interval Top: 8288 ft. Interval Bottom: 16193 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | 8/7/2018 | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 6/30/2018 | Treatment End Date: | 7/14/2018 | | Treatment Summary: | Completed Interval: 8,288' - 8,386'; 11,500' - 11,650'; 11,985' - 12,050'; 13,375' - 13,628'; 15,697' - 15,886'; 16,085' - 16,193' | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 8288 ft. | # Of Holes: | 970 | | Interval Bottom: | 16193 ft. | Hole Size: | 0.42 in. |
|
Formation NBFHC Formation Classification: OW Status: CM - 8/6/2018 Interval Top: 8288 ft. Interval Bottom: 17597 ft.| Completed Information for Formation NIOBRARA-FT HAYS-CODELL | | 1st Production Date: | 8/7/2018 | Choke Size: | | | Formation Name: | NIOBRARA-FT HAYS-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 6/30/2018 | Treatment End Date: | 7/14/2018 | | Treatment Summary: | 40 stages, 6,584,280 lbs 100Mesh white sand, 11,219,860 lbs 30/50 mesh regional sand, 2,152,320 lbs 30/50 white sand, 406,598 bbls Slickwater, 19,800 gal 15% concentration HCL acid.
| | Total fluid used in treatment (bbls): | 407069 | Max pressure during treatment (psi): | 8125 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 40 | | Total acid used in treatment (bbls): | 471 | Min frac gradient (psi/ft): | 0.99 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 31440 | | Fresh water used in treatment (bbls): | 406598 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 19956460 | Green completions techniques utilized: | No | | Reason green techniques Not utilized: PIPELINE |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7824 ft. | | Tubing Packer Depth: | 7811 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/6/2018 | Test Method: | Flowback | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | FLARED | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1090 | | BBLS_OIL | 169 | | BTU_GAS | 1486 | | CALC_BBLS_H2O | 1090 | | CALC_BBLS_OIL | 169 | | CALC_GOR | 663 | | CALC_MCF_GAS | 112 | | GRAVITY_OIL | 40 | | MCF_GAS | 112 | | TUBING_PRESS | 800 |
| | Perforation Data: | | Interval Top: | 8288 ft. | # Of Holes: | 1601 | | Interval Bottom: | 17597 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 8692 |
| Total Gas Produced (MCF) | 13695 |
| GOR | 1575 |
| GOR Determination | BOE |
| Average BOE per Day | 30.454 |
| Average MCFE per Day | 176.637 |
| Federal Financial Assurance | i | |
|
|
