Wellbore #00 Wellbore Classification: OW Status: PR - 10/1/2024 Measured TD: 18917 ft. Vertical TD: 6875 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 10/1/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 5/17/2019 | | Proposed Top PZ Location: | Sec:25 Twp: 5N 65W | Footage: 1883 FNL 494 FWL | | Bottom Hole Location: | Sec:27 Twp: 5N 65W | Footage: 1904 FNL 52 FWL | | Proposed Depth/Form: | 17092 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 400, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1600 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 920, Top: 0 ft., Bottom: 1600 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17092 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2035, Top: 0 ft., Bottom: 17092 ft. |
| | |
| Wellbore Completed | | Completion Date: | 4/26/2018 | | Spud Date: | 4/18/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 18917 ft. | Measured PB depth: | 18901 ft. | | True Vertical TD: | 6875 ft. | True Vertical PB depth: | 6876 ft. | | Top PZ Location: | Sec:25 Twp: 5N 65W | Footage: 1883 FNL 494 FWL | | Bottom Hole Location: | Sec:27 Twp: 5N 65W | Footage: 1904 FNL 52 FWL | | Log Types: | CBL, MWD (DIL in 123-32111) | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1632 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 760, Top: 0 ft., Bottom: 1632 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18916 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2720, Top: 2360 ft., Bottom: 18917 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3752 ft. | | | | | SUSSEX | 4576 ft. | | | | | SHARON SPRINGS | 7013 ft. | | | | | NIOBRARA | 7141 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 10/1/2024 Interval Top: 7864 ft. Interval Bottom: 18916 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 2/15/2019 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 1/3/2019 | Treatment End Date: | 1/15/2019 | | Treatment Summary: | 62 Stage Plug and Perf
Total Fluid: 215,407 bbls
Gel Fluid: 175,716 bbls
Slickwater Fluid: 38,305 bbls
15% HCl Acid: 1,386 bbls
Total Proppant: 11,694,830 lbs
Silica Proppant: 11,694,830 lbs
Method for determining flowback: measuring flowback tank volumes. | | Total fluid used in treatment (bbls): | 215407 | Max pressure during treatment (psi): | 4675 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 62 | | Total acid used in treatment (bbls): | 1386 | Min frac gradient (psi/ft): | 1.02 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 9825 | | Fresh water used in treatment (bbls): | 214021 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11694830 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7323 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/24/2019 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 216 | | BBLS_OIL | 366 | | BTU_GAS | 1310 | | CALC_BBLS_H2O | 216 | | CALC_BBLS_OIL | 366 | | CALC_GOR | 4596 | | CALC_MCF_GAS | 1682 | | CASING_PRESS | 2875 | | GRAVITY_OIL | 57 | | MCF_GAS | 1682 | | TUBING_PRESS | 2082 |
| | Perforation Data: | | Interval Top: | 7864 ft. | # Of Holes: | 2202 | | Interval Bottom: | 18916 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 7015 |
| Total Gas Produced (MCF) | 1557 |
| GOR | 221 |
| GOR Determination | BOE |
| Average BOE per Day | 19.975 |
| Average MCFE per Day | 115.863 |
| Federal Financial Assurance | i | |
|
|
