Wellbore #00 Wellbore Classification: OW Status: PR - 3/1/2023 Measured TD: 16337 ft. Vertical TD: 6307 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/1/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/28/2018 | | Proposed Top PZ Location: | Sec:4 Twp: 3N 62W | Footage: 1052 FNL 493 FEL | | Bottom Hole Location: | Sec:5 Twp: 3N 62W | Footage: 1043 FNL 401 FWL | | Proposed Depth/Form: | 16078 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | STATE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-1703 , Unit Acreage: 1280, Drill Unit: Sec 4 & 5: All | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 800 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 430, Top: 0 ft., Bottom: 800 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 6587 ft., Weight: 26 , Citings Type: PLANNED | | Cement: | Sacks: 550, Top: 600 ft., Bottom: 6587 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 5700 ft., Depth: 16346 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 700, Top: 5700 ft., Bottom: 16346 ft. |
| | |
| Wellbore Completed | | Completion Date: | 11/1/2017 | | Spud Date: | 9/27/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 16337 ft. | Measured PB depth: | 16276 ft. | | True Vertical TD: | 6307 ft. | True Vertical PB depth: | 6303 ft. | | Top PZ Location: | Sec:4 Twp: 3N 62W | Footage: 1052 FNL 493 FEL | | Bottom Hole Location: | Sec:5 Twp: 3N 62W | Footage: 1043 FNL 401 FWL | | Log Types: | MWD/LWD, CBL, Mud, (Resistivity on 123-43464). | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 818 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 216, Top: 0 ft., Bottom: 818 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 6536 ft., Weight: 26 , Citings Type: ACTUAL | | Cement: | Sacks: 660, Top: 1700 ft., Bottom: 6536 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 5704 ft., Depth: 16333 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 773, Top: 5704 ft., Bottom: 16333 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3421 ft. | | N | N | | SUSSEX | 4042 ft. | | N | N | | SHANNON | 4588 ft. | | N | N | | SHARON SPRINGS | 5943 ft. | | | | | NIOBRARA | 6120 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 3/1/2023 Interval Top: 6609 ft. Interval Bottom: 16246 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/13/2018 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/19/2018 | Treatment End Date: | 1/21/2018 | | Treatment Summary: | 80 STAGE WET SHOE PLUG AND PERF 10,931,843 LBS 20/40 SAND, 1,061,607 LBS 100# MESH, 1,613 BBLS 15% HCL ACID, AND 172,455 BBLS SLICKWATER | | Total fluid used in treatment (bbls): | 174068 | Max pressure during treatment (psi): | 7187 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 80 | | Total acid used in treatment (bbls): | 1613 | Min frac gradient (psi/ft): | 0.93 | | Recycled water used in treatment (bbls): | 14313 | Total flowback volume recovered (bbls): | 11221 | | Fresh water used in treatment (bbls): | 158142 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11993450 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6318 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/2/2018 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 394 | | BBLS_OIL | 155 | | BTU_GAS | 1479 | | CALC_BBLS_H2O | 394 | | CALC_BBLS_OIL | 155 | | CALC_GOR | 503 | | CALC_MCF_GAS | 78 | | CASING_PRESS | 1029 | | GRAVITY_OIL | 34 | | MCF_GAS | 78 | | TUBING_PRESS | 545 |
| | Perforation Data: | | Interval Top: | 6609 ft. | # Of Holes: | 2880 | | Interval Bottom: | 16246 ft. | Hole Size: | 0.37 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 3968 |
| Total Gas Produced (MCF) | 20036 |
| GOR | 5049 |
| GOR Determination | BOE |
| Average BOE per Day | 20.335 |
| Average MCFE per Day | 117.918 |
| Federal Financial Assurance | i | |
|
|
