Wellbore #00 Wellbore Classification: OW Status: PR - 3/1/2025 Measured TD: 7261 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/1/2025 | | Wellbore Permit | | | Permit #: | | Expiration Date: | 12/18/2013 | | Proposed Depth/Form: | 7800 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-87 , Unit Acreage: 80, Drill Unit: E2 NE4 | | Formation And Spacing: | Code: JSND , Formation: J SAND , Order: , Unit Acreage: 80, Drill Unit: E2 NE4 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-87 , Unit Acreage: 80, Drill Unit: E2 NE4 | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 600 ft., Weight: 24 , Citings Type: PLANNED | | Cement: | Sacks: 550, Top: 0 ft., Bottom: 600 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7800 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 650, Top: 0 ft., Bottom: 7800 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/7/2012 | | Spud Date: | 5/3/2012 | Spud Date Is: | ACTUAL | | Measured TD: | 7261 ft. | Measured PB depth: | 7176 ft. | | True Vertical TD: | | True Vertical PB depth: | | | Log Types: | HIGH RESOLUTION INDUCTION, DENSITY, NEUTRON, GAMMA, CBL | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 632 ft., Weight: 24 , Citings Type: ACTUAL | | Cement: | Sacks: 450, Top: 0 ft., Bottom: 632 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7261 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 650, Top: 2311 ft., Bottom: 7261 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3694 ft. | | | | | SUSSEX | 4310 ft. | | | | | NIOBRARA | 6788 ft. | | | | | FORT HAYS | 7057 ft. | | | | | CODELL | 7090 ft. | | | |
Formation CODL Formation Classification: OW Status: CM - 5/15/2013 Interval Top: 7088 ft. Interval Bottom: 7108 ft.| Completed Information for Formation CODELL | | 1st Production Date: | 6/20/2012 | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | Yes |
| | Formation Treatment | | Treatment Date: | 5/18/2012 | | Treatment Summary: | Slickwater frac on the Codell with a total of 153,755 of FR-Water, 70,340 lbs 30/50 White Sand. |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 7088 ft. | # Of Holes: | 80 | | Interval Bottom: | 7108 ft. | Hole Size: | 0.41 in. |
|
Formation NB-CD Formation Classification: OW Status: PR - 3/1/2025 Interval Top: 6910 ft. Interval Bottom: 7108 ft.| Completed Information for Formation NIOBRARA-CODELL | | 1st Production Date: | 6/20/2012 | Choke Size: | | | Formation Name: | NIOBRARA-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7076 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 6/20/2012 | Test Method: | flowing | | Hours Tested: | 16 | Gas Type: | SHALE | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 15 | | BBLS_OIL | 72 | | BTU_GAS | 1250 | | CALC_BBLS_H2O | 15 | | CALC_BBLS_OIL | 72 | | CALC_GOR | 3430 | | CALC_MCF_GAS | 247 | | CASING_PRESS | 1100 | | GRAVITY_OIL | 48 | | MCF_GAS | 247 | | TUBING_PRESS | 900 |
| | Perforation Data: | | Interval Top: | 6910 ft. | # Of Holes: | 168 | | Interval Bottom: | 7108 ft. | Hole Size: | 0.41 in. |
|
Formation NBRR Formation Classification: OW Status: CM - 5/15/2013 Interval Top: 6910 ft. Interval Bottom: 6932 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 6/20/2012 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | Yes |
| | Formation Treatment | | Treatment Date: | 5/18/2012 | | Treatment Summary: | Slickwater frac on the Niobrara with a total of 176,005 of FR-Water, 90,720 30/50 White Sand, and 1000 gal of 15%HCL Acid. |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 6910 ft. | # Of Holes: | 88 | | Interval Bottom: | 6932 ft. | Hole Size: | 0.41 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 502 |
| Total Gas Produced (MCF) | 6261 |
| GOR | 12472 |
| GOR Determination | BOE |
| Average BOE per Day | 4.303 |
| Average MCFE per Day | 24.945 |
| Federal Financial Assurance | i | |
|
|
