COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-34651		Well Classification: OW Status: PR - 2/1/2025
Well Name/No:SRC Bestway #14-2-11-14CHZM
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date2/1/2025
FacilityID:426323LocationID:423325
Municipality/County:GREELEY / WELD #123Location:SENE 2 5N66W 6
Field:WATTENBERG - #90750Elevation:4714 ft.
Basin:DENVER (DJ) BASIN
Planned Location:2255FNL  1141 FELLat/Long: 40.431194 / -104.739122Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.431194 / -104.739122Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 10/29/2015
End Date: 11/4/2015
Reported: 11/16/2015
Days to report: 12
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: AB - 12/1/2015             Measured TD: 11333 ft.    Vertical TD: 7137 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        AB - 12/1/2015
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:10/21/2015
Proposed Top PZ Location:Sec:11 Twp: 5N 66W Footage: 3066 FNL  2759 FEL
Bottom Hole Location:Sec:11 Twp: 5N 66W Footage: 3066 FNL  2759 FEL
Proposed Depth/Form:7889 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CLCDFH, Formation: CARLILE-CODELL-FORT HAYS , Order: , Unit Acreage: 648, Drill Unit: GWA
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 480, Drill Unit: GWA
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1200 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 450, Top: 0 ft., Bottom: 1200 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7300 ft., Weight: 29 , Citings Type: PLANNED
Cement:Sacks: 600, Top: 3000 ft., Bottom: 7300 ft.
Casing:String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6900 ft., Depth: 15945 ft., Weight: 13.5 , Citings Type: PLANNED
Cement:Sacks: , Top: , Bottom:
Wellbore Completed
Completion Date:6/22/2015
Spud Date:6/16/2015Spud Date Is:ACTUAL
Measured TD:11333 ft.Measured PB depth:8315 ft.
True Vertical TD:7137 ft.True Vertical PB depth:7100 ft.
Top PZ Location:Sec:11 Twp: 5N 66WFootage: 3066 FNL  2759 FEL
Bottom Hole Location:Sec:11 Twp: 5N 66WFootage: 3066 FNL  2759 FEL
Log Types:MWD/LWD, CBL, Mud Log (Triple Combo in 05.123.34640)
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 60 ft., Weight: 65 , Citings Type: ACTUAL
Cement:Sacks: 43, Top: 0 ft., Bottom: 60 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1237 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 420, Top: 0 ft., Bottom: 1237 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 8429 ft., Weight: 29 , Citings Type: ACTUAL
Cement:Sacks: 930, Top: 195 ft., Bottom: 8429 ft., Determination Method: CBL
Additional Cement:String Type: OPEN HOLE , Top: 8315 ft., Depth: 11308 ft., Bottom: 11308 ft., Sacks: 427, Method:
FormationInterval TopLog BottomCoredDSTs
PARKMAN3858 ft.NN
SUSSEX4495 ft.NN
SHANNON4840 ft.NN
SHARON SPRINGS7853 ft.NN
NIOBRARA7876 ft.NN
FORT HAYS8355 ft.NN
CODELL8425 ft.NN
CARLILE8550 ft.NN
  No formation data to display.

Sidetrack #01             Wellbore Classification: OW             Status: PR - 2/1/2025             Measured TD: 15266 ft.    Vertical TD: 7115 ft.

 Wellbore Data for Sidetrack #01Wellbore Classification: OW        PR - 2/1/2025
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:6/28/2017
Proposed Top PZ Location:Sec:11 Twp: 5N 66W Footage: 460 FNL  2686 FEL
Bottom Hole Location:Sec:14 Twp: 5N 66W Footage: 2144 FNL  2711 FEL
Proposed Depth/Form:15945 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 480, Drill Unit: GWA
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1238 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 425, Top: 0 ft., Bottom: 1238 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 8429 ft., Weight: 29 , Citings Type: PLANNED
Cement:Sacks: 930, Top: 0 ft., Bottom: 8249 ft.
Casing:String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7775 ft., Depth: 15945 ft., Weight: 13.5 , Citings Type: PLANNED
Cement:Sacks: , Top: , Bottom:
Wellbore Completed
Completion Date:7/10/2015
Spud Date:6/16/2015Spud Date Is:ACTUAL
Measured TD:15266 ft.Measured PB depth:15259 ft.
True Vertical TD:7115 ft.True Vertical PB depth:7115 ft.
Top PZ Location:Sec:11 Twp: 5N 66WFootage: 326 FNL  2673 FEL
Bottom Hole Location:Sec:14 Twp: 5N 66WFootage: 1446 FNL  2746 FEL
Log Types:MWD/LWD, CBL, Mud Log (Triple Combo in 05.123.34640)
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 60 ft., Weight: 65 , Citings Type: ACTUAL
Cement:Sacks: 43, Top: 0 ft., Bottom: 60 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1237 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 420, Top: 0 ft., Bottom: 1237 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 8429 ft., Weight: 29 , Citings Type: ACTUAL
Cement:Sacks: 930, Top: 195 ft., Bottom: 8429 ft., Determination Method: CBL
Casing:String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7818 ft., Depth: 15262 ft., Weight: 13.5 , Citings Type: ACTUAL
Cement:Sacks: 500, Top: 7818 ft., Bottom: 14978 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PARKMAN3858 ft.NN
SUSSEX4495 ft.NN
SHANNON4840 ft.NN
SHARON SPRINGS7853 ft.NN
NIOBRARA7876 ft.NN
FORT HAYS8355 ft.NN
CODELL8425 ft.NN
CARLILE8550 ft.NN

Formation FTHYS                   Formation Classification:  OW                   Status:  CM - 11/6/2017                 Interval Top: 9000 ft.    Interval Bottom: 13500 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:11/10/2015Choke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:10/26/2015Treatment End Date:11/4/2015
Treatment Summary:Fort Hays Depths: 9000-9300, 11200-11850, 12750-13500
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:9000 ft.# Of Holes:1014
Interval Bottom:13500 ft.Hole Size:0.43 in.

Formation CARL                     Formation Classification:  OW                     Status:  CM - 11/6/2017                 Interval Top: 8550 ft.    Interval Bottom: 13950 ft.

 Completed Information for Formation CARLILE
1st Production Date:11/10/2015Choke Size:
Formation Name:CARLILECommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:10/26/2015Treatment End Date:11/4/2015
Treatment Summary:Carlile Depths: 8550-8750, 13670-13950
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CARL.
Perforation Data:
Interval Top:8550 ft.# Of Holes:1014
Interval Bottom:13950 ft.Hole Size:0.43 in.

Formation CLCDFH                 Formation Classification:  OW                 Status:  PR - 2/1/2025                  Interval Top: 8480 ft.    Interval Bottom: 15266 ft.

 Completed Information for Formation CARLILE-CODELL-FORT HAYS
1st Production Date:11/10/2015Choke Size:
Formation Name:CARLILE-CODELL-FORT HAYSCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:10/26/2015Treatment End Date:11/5/2015
Treatment Summary:Plug and perf completion type. 37 stages: 190474 bbl of Slickwater, No Acid, 4444202 lbs of proppant (40/70 and 100 mesh sand) used in treatment. Test method flowing, used frac reports for data.
Total fluid used in treatment (bbls):190474Max pressure during treatment (psi):8580
Total gas used in treatment (mcf):0Fluid density (lbs/gal):8.33
Type Of gas:Number Of staged intervals:37
Total acid used in treatment (bbls):0Min frac gradient (psi/ft):0.92
Recycled water used in treatment (bbls):0Total flowback volume recovered (bbls):27645
Fresh water used in treatment (bbls):190474Disposition method For flowback:DISPOSAL
Total proppant used (lbs):4444202Green completions techniques utilized:Yes
Reason green techniques Not utilized:
Tubing Size:2.375 in.Tubing Setting Depth:7752 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:11/29/2015Test Method:Flowing
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 487
BBLS_OIL 301
BTU_GAS 1269
CALC_BBLS_H2O 487
CALC_BBLS_OIL 301
CALC_GOR 14265
CALC_MCF_GAS 4294
CASING_PRESS 2400
GRAVITY_OIL 54
MCF_GAS 4294
TUBING_PRESS 1250
Perforation Data:
Interval Top:8480 ft.# Of Holes:1014
Interval Bottom:15266 ft.Hole Size:0.43 in.

Formation CODL                     Formation Classification:  OW                     Status:  CM - 11/6/2017                 Interval Top: 8480 ft.    Interval Bottom: 15266 ft.

 Completed Information for Formation CODELL
1st Production Date:11/10/2015Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:10/26/2015Treatment End Date:11/4/2015
Treatment Summary:Codell Depths: 8480-8550, 8750-9000, 9300-11200, 11850-12750, 13500-13670, 13950-15266
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:8480 ft.# Of Holes:1014
Interval Bottom:15266 ft.Hole Size:0.43 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
November 2024 - October 2025i
Total Oil Produced (Barrels)4384
Total Gas Produced (MCF)44793
GOR10217
GOR DeterminationBOE
Average BOE per Day33.470
Average MCFE per Day194.122

 Federal Financial Assurance  i

 Tribal Well  i No
