COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-103-11034		Well Classification: GW Status: PA - 5/1/2023
Well Name/No:BOIES #B-19P-P3
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:TEP ROCKY MOUNTAIN LLC - 96850
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date5/1/2023
FacilityID:291112LocationID:335891
County:RIO BLANCO #103Location:SESE 19 2S97W 6
Field:SULPHUR CREEK - #80090Elevation:6248 ft.
Basin:PICEANCE BASIN
Planned Location:328FSL  1051 FELLat/Long: 39.855490 / -108.318940Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.855386 / -108.319021Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PA - 5/1/2023             Measured TD: 11394 ft.    Vertical TD: 11364 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PA - 5/1/2023
Wellbore PermitDIRECTIONAL
Permit #:20072423 Expiration Date:6/19/2008
Proposed Top PZ Location:Sec:19 Twp: 2S 97W Footage: 538 FSL  612 FEL
Bottom Hole Location:Sec:19 Twp: 2S 97W Footage: 538 FSL  612 FEL
Proposed Depth/Form:11377 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: ILES , Formation: ILES , Order: 527-2 , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: SEGO , Formation: SEGO , Order: 527-2 , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: 527-1 , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:3/22/2008
Spud Date:2/24/2008Spud Date Is:ACTUAL
Measured TD:11394 ft.Measured PB depth:11319 ft.
True Vertical TD:11364 ft.True Vertical PB depth:11289 ft.
Top PZ Location:Sec:19 Twp: 2S 97WFootage: 538 FSL  612 FEL
Bottom Hole Location:Sec:19 Twp: 2S 97WFootage: 538 FSL  612 FEL
Log Types:AL, HVC, CPD/CPN, TRIPLE COMB, CBL
Casing:String Type: CONDUCTOR, Hole Size: , Size: , Top: 0 ft., Depth: 130 ft., Weight: UNK , Citings Type: ACTUAL
Cement:Sacks: , Top: 0 ft., Bottom: 130 ft., Determination Method:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: , Depth: 5188 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 595, Top: 1936 ft., Bottom: 5188 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 11394 ft., Weight: 11.60 , Citings Type: ACTUAL
Cement:Sacks: 1042, Top: 7462 ft., Bottom: 11394 ft., Determination Method: CALC
Casing:String Type: S.C. 1.1, Hole Size: , Size: , Top: , Depth: 1936 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 480, Top: 0 ft., Bottom: 1936 ft., Determination Method: CALC
Casing:String Type: STAGE TOOL, Hole Size: , Size: 9.625 in., Top: , Depth: 1936 ft., Weight: - , Citings Type: ACTUAL
Cement:Sacks: 480, Top: 0 ft., Bottom: 1936 ft., Determination Method: VISU
FormationInterval TopLog BottomCoredDSTs
OHIO CREEK6014 ft.NN
WILLIAMS FORK6189 ft.NN
CAMEO9461 ft.NN
ROLLINS9968 ft.NN
COZZETTE10110 ft.NN
CORCORAN10461 ft.NN
SEGO11252 ft.NN

Formation CRCRN                   Formation Classification:  GW                   Status:  AB - 5/1/2023                  Interval Top: 10466 ft.    Interval Bottom: 10961 ft.

 Completed Information for Formation CORCORAN
1st Production Date:9/29/2008Choke Size:0.313 in.
Formation Name:CORCORANCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:9/22/2008
Treatment Summary:10466'-10961' - 346684# 20/40 WH SAND, 7305 BBLS SLICKWATER
Tubing Size:2.375 in.Tubing Setting Depth:8689 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:10/24/2008Test Method:SEPARATOR/EFM
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 142
BBLS_OIL 1
BTU_GAS 1073
CALC_BBLS_H2O 142
CALC_BBLS_OIL 1
CALC_GOR 715000
CALC_MCF_GAS 715
CASING_PRESS 14780
GRAVITY_OIL 48
MCF_GAS 715
Perforation Data:
Interval Top:10466 ft.# Of Holes:38
Interval Bottom:10961 ft.Hole Size:0.35 in.

Formation COZZ                     Formation Classification:  GW                     Status:  AB - 5/1/2023                  Interval Top: 10114 ft.    Interval Bottom: 10385 ft.

 Completed Information for Formation COZZETTE
1st Production Date:9/29/2008Choke Size:0.313 in.
Formation Name:COZZETTECommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:9/24/2008
Treatment Summary:145431# 30/50 WH SAND, 3064 BBLS SLICKWATER
Tubing Size:2.375 in.Tubing Setting Depth:8689 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:10/24/2008Test Method:SEPARATOR/EFM
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 35
BBLS_OIL 1
BTU_GAS 1073
CALC_BBLS_H2O 35
CALC_BBLS_OIL 1
CALC_GOR 178000
CALC_MCF_GAS 178
CASING_PRESS 1480
GRAVITY_OIL 48
MCF_GAS 178
Perforation Data:
Interval Top:10114 ft.# Of Holes:19
Interval Bottom:10385 ft.Hole Size:0.35 in.

Formation WFCM                     Formation Classification:  GW                     Status:  AB - 5/1/2023                  Interval Top: 8256 ft.    Interval Bottom: 9901 ft.

 Completed Information for Formation WILLIAMS FORK - CAMEO
1st Production Date:9/29/2008Choke Size:0.313 in.
Formation Name:WILLIAMS FORK - CAMEOCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:9/24/2008
Treatment Summary:8256'-9901' - 633139# 30/50 WH SAND, 13340 BBLS SLICKWATER
Tubing Size:2.375 in.Tubing Setting Depth:8689 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:10/24/2008Test Method:SEPARATOR/EFM
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 197
BBLS_OIL 2
BTU_GAS 1073
CALC_BBLS_H2O 197
CALC_BBLS_OIL 2
CALC_GOR 499500
CALC_MCF_GAS 999
CASING_PRESS 1480
GRAVITY_OIL 48
MCF_GAS 999
Perforation Data:
Interval Top:8256 ft.# Of Holes:84
Interval Bottom:9901 ft.Hole Size:0.35 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY05/01/2023
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR DeterminationMCFE
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
