Wellbore #00 Wellbore Classification: DSPW Status: IJ - 8/1/2025 Measured TD: 8130 ft. Vertical TD: 7707 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: DSPW IJ - 8/1/2025 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 11/26/2018 | | Proposed Top PZ Location: | Sec:8 Twp: 7S 95W | Footage: 1294 FNL 1312 FEL | | Bottom Hole Location: | Sec:8 Twp: 7S 95W | Footage: 1303 FNL 1327 FEL | | Proposed Depth/Form: | 8130 ft. | | Surface Mineral Owner Same: | Not available | | Mineral Owner: | Not available | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CZ-CR , Formation: COZZETTE-CORCORAN , Order: , Unit Acreage: , Drill Unit: | | Formation And Spacing: | Code: ILES , Formation: ILES , Order: , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 77 ft., Weight: 75 , Citings Type: PLANNED | | Cement: | Sacks: 70, Top: 0 ft., Bottom: 77 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 267, Top: 0 ft., Bottom: 1700 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 8130 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 755, Top: , Bottom: 8130 ft. |
| | |
| Wellbore Completed | | Completion Date: | 11/18/2017 | | Spud Date: | 11/10/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 8130 ft. | Measured PB depth: | 8060 ft. | | True Vertical TD: | 7707 ft. | True Vertical PB depth: | 7637 ft. | | Top PZ Location: | Sec:8 Twp: 7S 95W | Footage: 1294 FNL 1312 FEL | | Bottom Hole Location: | Sec:8 Twp: 7S 95W | Footage: 1303 FNL 1327 FEL | | Log Types: | CBL/Mud/Triple Combo | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 77 ft., Weight: 75 , Citings Type: ACTUAL | | Cement: | Sacks: 70, Top: 0 ft., Bottom: 77 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1726 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 301, Top: 0 ft., Bottom: 1726 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 8105 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 988, Top: 2452 ft., Bottom: 8105 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WILLIAMS FORK | 4018 ft. | | N | N | | CAMEO | 6664 ft. | | N | N | | ROLLINS | 7111 ft. | | N | N | | COZZETTE | 7398 ft. | | N | N | | CORCORAN | 7660 ft. | | N | N |
Formation CRCRN Formation Classification: DSPW Status: CM - 12/31/2018 Interval Top: 7699 ft. Interval Bottom: 7959 ft.| Completed Information for Formation CORCORAN | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CORCORAN | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CRCRN. |
| | Perforation Data: | | Interval Top: | 7699 ft. | # Of Holes: | 80 | | Interval Bottom: | 7959 ft. | Hole Size: | 0.43 in. |
|
Formation COZZ Formation Classification: DSPW Status: CM - 12/31/2018 Interval Top: 7413 ft. Interval Bottom: 7658 ft.| Completed Information for Formation COZZETTE | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | COZZETTE | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation COZZ. |
| | Perforation Data: | | Interval Top: | 7413 ft. | # Of Holes: | 89 | | Interval Bottom: | 7658 ft. | Hole Size: | 0.43 in. |
|
Formation CZ-CR Formation Classification: DSPW Status: IJ - 8/1/2025 Interval Top: 7413 ft. Interval Bottom: 7959 ft.| Completed Information for Formation COZZETTE-CORCORAN | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | COZZETTE-CORCORAN | Commingled: | No | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 8/27/2018 | Treatment End Date: | 9/26/2018 | | Treatment Summary: | Frac'd 298,451 bbls 2% slickwater. | | Total fluid used in treatment (bbls): | 298451 | Max pressure during treatment (psi): | 5127 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.40 | | Type Of gas: | | Number Of staged intervals: | 2 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.78 | | Recycled water used in treatment (bbls): | 298451 | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.875 in. | Tubing Setting Depth: | 7363 ft. | | Tubing Packer Depth: | 7359 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CZ-CR. |
| | Perforation Data: | | Interval Top: | 7413 ft. | # Of Holes: | 169 | | Interval Bottom: | 7959 ft. | Hole Size: | 0.43 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 0 |
| Total Gas Produced (MCF) | 0 |
| GOR | |
| GOR Determination | |
| Average BOE per Day | 0.000 |
| Average MCFE per Day | 0.000 |
| Federal Financial Assurance | i | |
|
|
