Wellbore #00 Wellbore Classification: GW Status: PR - 5/1/2012 Measured TD: 10345 ft. Vertical TD: 10217 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 5/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 8/3/2012 | | Proposed Top PZ Location: | Sec:15 Twp: 6S 96W | Footage: 1565 FSL 1635 FWL | | Bottom Hole Location: | Sec:15 Twp: 6S 96W | Footage: 1565 FSL 1635 FWL | | Proposed Depth/Form: | 10371 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-13 , Unit Acreage: , Drill Unit: NWSW | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: , Depth: 90 ft., Weight: 55 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 90 ft. | | Casing: | String Type: SURF, Hole Size: 16 in., Size: 9.625 in., Top: , Depth: 2500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 1000, Top: 0 ft., Bottom: 2500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 10171 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1200, Top: 6500 ft., Bottom: 10171 ft. | | Casing: | String Type: 3RD, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 10371 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 600, Top: , Bottom: 10371 ft. |
| | |
| Wellbore Completed | | Completion Date: | 12/5/2010 | | Spud Date: | 11/20/2010 | Spud Date Is: | ACTUAL | | Measured TD: | 10345 ft. | Measured PB depth: | 10345 ft. | | True Vertical TD: | 10217 ft. | True Vertical PB depth: | 10217 ft. | | Top PZ Location: | Sec:15 Twp: 6S 96W | Footage: 2341 FNL 577 FWL | | Bottom Hole Location: | Sec:15 Twp: 6S 96W | Footage: 2341 FNL 577 FWL | | Log Types: | CBL & RST combo to be run when drilling out of pad is completed. | | Log Types: | CBL & RST COMBO TO BE RUN WHEN DRILLING OUT OF PAD IS COMPLETED | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: 0 ft., Depth: 123 ft., Weight: 55 , Citings Type: ACTUAL | | Cement: | Sacks: 276, Top: 0 ft., Bottom: 123 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 16 in., Size: 9.625 in., Top: 0 ft., Depth: 2875 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 2430, Top: 0 ft., Bottom: 2875 ft., Determination Method: CALC | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 10292 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 811, Top: 4000 ft., Bottom: 10292 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | GREEN RIVER | 0 ft. | 2878 ft. | | | | WASATCH | 2878 ft. | 5524 ft. | | | | FORT UNION | 5524 ft. | 6948 ft. | | | | OHIO CREEK | 6948 ft. | 7151 ft. | | | | WILLIAMS FORK | 7151 ft. | 9802 ft. | | | | CAMEO | 9802 ft. | 10152 ft. | | | | ROLLINS | 10152 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 5/1/2012 Interval Top: 7600 ft. Interval Bottom: 9763 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 8/17/2011 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Date: | 7/25/2011 | | Treatment Summary: | 30/50 WHITESAND- 347,768 LBS
20/40 WHITESAND- 272,472 LBS
FLUID- 65,999 BBLS
ACID- 3,000 GALS |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9212 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/18/2011 | Test Method: | PRODUCING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 975 | | BTU_GAS | 1060 | | CALC_BBLS_H2O | 975 | | CALC_MCF_GAS | 3061 | | CASING_PRESS | 1900 | | MCF_GAS | 3061 | | TUBING_PRESS | 900 |
| | Perforation Data: | | Interval Top: | 7600 ft. | # Of Holes: | 208 | | Interval Bottom: | 9763 ft. | Hole Size: | 0.4 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 86 |
| Total Gas Produced (MCF) | 64356 |
| GOR | 748325 |
| GOR Determination | MCFE |
| Average BOE per Day | 30.488 |
| Average MCFE per Day | 176.824 |
| Federal Financial Assurance | i | |
|
|
