Wellbore #00 Wellbore Classification: OW Status: PR - 2/1/2025 Measured TD: 16823 ft. Vertical TD: 8105 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/22/2019 | | Proposed Top PZ Location: | Sec:35 Twp: 4S 65W | Footage: 1080 FNL 1950 FEL | | Bottom Hole Location: | Sec:34 Twp: 4S 65W | Footage: 1075 FNL 1150 FWL | | Proposed Depth/Form: | 16846 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | STATE | Surface Owner: | STATE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-779 , Unit Acreage: 1278, Drill Unit: Sec 34 & 35 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 50, Top: 0 ft., Bottom: 100 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2277 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 620, Top: 0 ft., Bottom: 2277 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 16845 ft., Weight: 23 , Citings Type: PLANNED | | Cement: | Sacks: 2040, Top: 2277 ft., Bottom: 16845 ft. |
| | |
| Wellbore Completed | | Completion Date: | 8/24/2017 | | Spud Date: | 8/5/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 16823 ft. | Measured PB depth: | 1650 ft. | | True Vertical TD: | 8105 ft. | True Vertical PB depth: | 1650 ft. | | Top PZ Location: | Sec:35 Twp: 4S 65W | Footage: 1080 FNL 1950 FEL | | Bottom Hole Location: | Sec:34 Twp: 4S 65W | Footage: 1075 FNL 1150 FWL | | Log Types: | MWD, Mud, GR, Res | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 126 ft., Weight: 65 , Citings Type: ACTUAL | | Cement: | Sacks: 50, Top: 0 ft., Bottom: 126 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2279 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 165, Top: 0 ft., Bottom: 2279 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 16811 ft., Weight: 23 , Citings Type: ACTUAL | | Cement: | Sacks: 2200, Top: 2108 ft., Bottom: 16811 ft., Determination Method: CBL | | Additional Cement: | String Type: SURF , Top: 1773 ft., Depth: 1773 ft., Bottom: 2278 ft., Sacks: 165, Method: STAGE TOOL | | Additional Cement: | String Type: SURF , Top: 0 ft., Depth: 1773 ft., Bottom: 1773 ft., Sacks: 605, Method: STAGE TOOL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | FOX HILLS | 1845 ft. | 2070 ft. | N | N | | PIERRE | 2070 ft. | 7927 ft. | N | N | | NIOBRARA | 7927 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 2/1/2025 Interval Top: 9355 ft. Interval Bottom: 16657 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 1/12/2018 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 12/4/2017 | Treatment End Date: | 12/13/2017 | | Treatment Summary: | Treatment Summary:
5,457,865 gallons of FR Water (FR-76)
367,349 gallons of Treated Water
82,062 gallons of 15% HCl Acid
747,380 pounds of 100 Mesh
3,228,590 pounds of 40/70 | | Total fluid used in treatment (bbls): | 140649 | Max pressure during treatment (psi): | 8686 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 0.71 | | Type Of gas: | | Number Of staged intervals: | 41 | | Total acid used in treatment (bbls): | 1954 | Min frac gradient (psi/ft): | 0.83 | | Recycled water used in treatment (bbls): | 8746 | Total flowback volume recovered (bbls): | 10709 | | Fresh water used in treatment (bbls): | 129949 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 3975970 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9292 ft. | | Tubing Packer Depth: | 9269 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 1/18/2018 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 541 | | BBLS_OIL | 541 | | BTU_GAS | 1446 | | CALC_BBLS_H2O | 541 | | CALC_BBLS_OIL | 541 | | CALC_GOR | 1123 | | CALC_MCF_GAS | 809 | | GRAVITY_OIL | 40 | | MCF_GAS | 809 | | TUBING_PRESS | 1550 |
| | Perforation Data: | | Interval Top: | 9355 ft. | # Of Holes: | 1293 | | Interval Bottom: | 16657 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 4344 |
| Total Gas Produced (MCF) | 101 |
| GOR | 23 |
| GOR Determination | BOE |
| Average BOE per Day | 11.908 |
| Average MCFE per Day | 69.038 |
| Federal Financial Assurance | i | |
|
|
