Wellbore #00 Wellbore Classification: OW Status: PR - 8/28/2024 Measured TD: 18235 ft. Vertical TD: 7958 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 8/28/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 11/2/2028 | | Proposed Top PZ Location: | Sec:25 Twp: 4S 65W | Footage: 1100 FNL 330 FEL | | Bottom Hole Location: | Sec:26 Twp: 4S 65W | Footage: 1100 FNL 330 FWL | | Proposed Depth/Form: | 17973 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1442 , Unit Acreage: 1280, Drill Unit: T4S R65W SEC 25: ALL | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 105, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3255 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 1325, Top: 0 ft., Bottom: 3255 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17973 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2834, Top: , Bottom: 17973 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7140 ft., Depth: 12530 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 0, Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 12/13/2023 | | Spud Date: | 12/3/2023 | Spud Date Is: | ACTUAL | | Measured TD: | 18235 ft. | Measured PB depth: | 18225 ft. | | True Vertical TD: | 7958 ft. | True Vertical PB depth: | 7958 ft. | | Top PZ Location: | Sec:25 Twp: 4S 65W | Footage: 1118 FNL 349 FEL | | Bottom Hole Location: | Sec:26 Twp: 4S 65W | Footage: 1123 FNL 334 FWL | | Log Types: | CBL, MWD, RES | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 100 ft., Weight: 36.95 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 100 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3297 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1353, Top: 0 ft., Bottom: 3297 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18225 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2855, Top: 550 ft., Bottom: 18225 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 5030 ft. | | N | N | | SUSSEX | 5359 ft. | | N | N | | SHANNON | 6259 ft. | | N | N | | SHARON SPRINGS | 7722 ft. | | N | N | | NIOBRARA | 7799 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 8/28/2024 Interval Top: 8378 ft. Interval Bottom: 18155 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 8/22/2024 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 5/6/2024 | Treatment End Date: | 5/15/2024 | | Treatment Summary: | Frac'd Niobrara with 62 stage plug and perf:
11369207 total pounds proppant pumped: 73600 pounds 40/70 mesh; 11295607 pounds 100 mesh;
479600 total bbls fluid pumped: 451993 bbls gelled fluid; 23144 bbls fresh water and 4463 bbls 15% HCl Acid.
| | Total fluid used in treatment (bbls): | 479600 | Max pressure during treatment (psi): | 9075 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 62 | | Total acid used in treatment (bbls): | 4463 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 23144 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11369207 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7907 ft. | | Tubing Packer Depth: | 7905 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/28/2024 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 217 | | BBLS_OIL | 396 | | BTU_GAS | 1400 | | CALC_BBLS_H2O | 217 | | CALC_BBLS_OIL | 396 | | CALC_GOR | 934 | | CALC_MCF_GAS | 370 | | CASING_PRESS | 25 | | GRAVITY_OIL | 40 | | MCF_GAS | 370 | | TUBING_PRESS | 1162 |
| | Perforation Data: | | Interval Top: | 8378 ft. | # Of Holes: | 3374 | | Interval Bottom: | 18155 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 46222 |
| Total Gas Produced (MCF) | 116043 |
| GOR | 2510 |
| GOR Determination | BOE |
| Average BOE per Day | 181.906 |
| Average MCFE per Day | 1055.060 |
| Federal Financial Assurance | i | |
|
|
