Wellbore #00 Wellbore Classification: OW Status: PR - 5/13/2022 Measured TD: 18398 ft. Vertical TD: 7942 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 5/13/2022 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/18/2020 | | Proposed Top PZ Location: | Sec:4 Twp: 1S 67W | Footage: 460 FNL 1222 FWL | | Bottom Hole Location: | Sec:9 Twp: 1S 67W | Footage: 299 FSL 1228 FWL | | Proposed Depth/Form: | 18171 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CARL , Formation: CARLILE , Order: 407-3710 , Unit Acreage: 640, Drill Unit: W2 Sec 4; W2 Sec 9 | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-3710 , Unit Acreage: 640, Drill Unit: W2 Sec 4; W2 Sec 9 | | Formation And Spacing: | Code: FTHYS , Formation: FORT HAYS , Order: 407-3710 , Unit Acreage: 640, Drill Unit: W2 Sec 4; W2 Sec 9 | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3710 , Unit Acreage: 640, Drill Unit: W2 Sec 4; W2 Sec 9 | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1700 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 707, Top: 0 ft., Bottom: 1700 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18171 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2302, Top: 0 ft., Bottom: 18171 ft. |
| | |
| Wellbore Completed | | Completion Date: | 7/21/2021 | | Spud Date: | 4/4/2020 | Spud Date Is: | ACTUAL | | Measured TD: | 18398 ft. | Measured PB depth: | 18393 ft. | | True Vertical TD: | 7942 ft. | True Vertical PB depth: | 7942 ft. | | Top PZ Location: | Sec:4 Twp: 1S 67W | Footage: 460 FNL 1222 FWL | | Bottom Hole Location: | Sec:9 Twp: 1S 67W | Footage: 299 FSL 1228 FWL | | Log Types: | | | Log Types: | Mud, MWD/LWD, CBL (Composite in 001-09962) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2026 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 930, Top: 0 ft., Bottom: 2026 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18398 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2655, Top: 2860 ft., Bottom: 18398 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4466 ft. | 4719 ft. | N | N | | SUSSEX | 4898 ft. | 5170 ft. | N | N | | SHANNON | 5604 ft. | 5795 ft. | N | N | | SHARON SPRINGS | 7759 ft. | | N | N | | NIOBRARA | 7913 ft. | | N | N | | FORT HAYS | 8593 ft. | | N | N | | CODELL | 8777 ft. | | N | N |
Formation FTHYS Formation Classification: OW Status: CM - 10/2/2024 Interval Top: 9042 ft. Interval Bottom: 11945 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 10/2/2024 | Treatment End Date: | N/A | | Treatment Summary: | Fort Hays intervals: 9042'-9067', 9316',-9587', 11838,-11945. | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 9042 ft. | # Of Holes: | 1244 | | Interval Bottom: | 11945 ft. | Hole Size: | 0.31 in. |
|
Formation CODL Formation Classification: OW Status: CM - 10/2/2024 Interval Top: 8860 ft. Interval Bottom: 18398 ft.| Completed Information for Formation CODELL | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 10/2/2024 | Treatment End Date: | N/A | | Treatment Summary: | Codell intervals: 8860'-9042', 9067'-9316',9587-11838', 11945'-18398 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 8860 ft. | # Of Holes: | 1244 | | Interval Bottom: | 18398 ft. | Hole Size: | 0.31 in. |
|
Formation NBFHC Formation Classification: OW Status: PR - 5/13/2022 Interval Top: 8860 ft. Interval Bottom: 18176 ft.| Completed Information for Formation NIOBRARA-FT HAYS-CODELL | | 1st Production Date: | 5/11/2022 | Choke Size: | | | Formation Name: | NIOBRARA-FT HAYS-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 2/18/2022 | Treatment End Date: | 3/21/2022 | | Treatment Summary: | 1955 bbls 15% HCL Acid;
851,452 # 100 Mesh Sand; 2,646,961 # 20/40 Mesh Sand; 4,101,199 # 30/50 Mesh Sand; 1,657,050 # 40/70 Mesh Sand;
309,575 bbls Gelled Fluid;
Flowback determined from well test separator | | Total fluid used in treatment (bbls): | 311530 | Max pressure during treatment (psi): | 4021 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 37 | | Total acid used in treatment (bbls): | 1955 | Min frac gradient (psi/ft): | 0.80 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 22190 | | Fresh water used in treatment (bbls): | 309575 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 9256662 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8494 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 5/13/2022 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 138 | | BBLS_OIL | 452 | | BTU_GAS | 1409 | | CALC_BBLS_H2O | 138 | | CALC_BBLS_OIL | 452 | | CALC_GOR | 1956 | | CALC_MCF_GAS | 884 | | CASING_PRESS | 2136 | | GRAVITY_OIL | 44 | | MCF_GAS | 884 | | TUBING_PRESS | 1684 |
| | Perforation Data: | | Interval Top: | 8860 ft. | # Of Holes: | 1244 | | Interval Bottom: | 18176 ft. | Hole Size: | 0.31 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 22687 |
| Total Gas Produced (MCF) | 364003 |
| GOR | 16044 |
| GOR Determination | MCFE |
| Average BOE per Day | 234.026 |
| Average MCFE per Day | 1357.367 |
| Federal Financial Assurance | i | |
|
|
