COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-125-10365		Well Classification: GW Status: PR - 9/1/2007
Well Name/No:BRUEGGEMAN #24-14
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:OWN RESOURCES OPERATING LLC - 10699
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date9/1/2007
FacilityID:286906LocationID:337581
County:YUMA #125Location:SESW 14 1S45W 6
Field:DUKE - #18890Elevation:3897 ft.
Planned Location:730FSL  2385 FWLLat/Long: 39.963610 / -102.384110Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.963620 / -102.384110Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 9/1/2007             Measured TD: 2451 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 9/1/2007
Wellbore Permit
Permit #:20063661 Expiration Date:9/20/2007
Proposed Depth/Form:2450 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:5/5/2007
Spud Date:5/2/2007Spud Date Is:ACTUAL
Measured TD:2451 ft.Measured PB depth:2407 ft.
True Vertical TD:True Vertical PB depth:
Log Types:CBL, CNL/CDL, DUAL INDUCTION
Casing:String Type: SURF, Hole Size: 9.5 in., Size: 7 in., Top: 0 ft., Depth: 419 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 115, Top: 0 ft., Bottom: 419 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 6.25 in., Size: 4.5 in., Top: 0 ft., Depth: 2433 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 75, Top: 1530 ft., Bottom: 2433 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
NIOBRARA2269 ft.NN

Formation NBRR                     Formation Classification:  GW                     Status:  PR - 9/1/2007                  Interval Top: 2289 ft.    Interval Bottom: 2301 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:7/10/2007Choke Size:1.000 in.
Formation Name:NIOBRARACommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:6/6/2007
Treatment Summary:FRAC'D NBRR W/500 GAL 15% HCL ACID, 60 QUALITY CO2, 556 BBLS OF MAV3 GUAR GEL FLUID SYSTEM, 100,000 LBS OF 16/30 MESH BADGER SAND, 60 TONS OF CO2.
Tubing Size:2.375 in.Tubing Setting Depth:2342 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:9/1/2007Test Method:FLOWING
Hours Tested:24Gas Type:SHALE
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 0
BBLS_OIL 0
BTU_GAS 937
CALC_BBLS_H2O 0
CALC_BBLS_OIL 0
CALC_MCF_GAS 146
CASING_PRESS 178
MCF_GAS 146
Perforation Data:
Interval Top:2289 ft.# Of Holes:24
Interval Bottom:2301 ft.Hole Size:0.42 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
April 2024 - March 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)7822
GOR
GOR DeterminationMCFE
Average BOE per Day3.693
Average MCFE per Day21.428

 Federal Financial Assurance  i

 Tribal Well  i No
