COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-51217		Well Classification: LO Status: AL - 12/27/2023
Well Name/No:Mule Deer #44-32-29XRLNB
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:BONANZA CREEK ENERGY OPERATING COMPANY LLC - 8960
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:ALStatus Date12/27/2023
FacilityID:477800LocationID:438694
County:WELD #123Location:Lot 2 5 5N61W 6
Field:WATTENBERG - #90750Elevation:4659 ft.
Basin:DENVER (DJ) BASIN
Planned Location:336FNL  2131 FELLat/Long: 40.436524 / -104.231334Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: AL - 12/27/2023             Measured TD:

 Wellbore Data for Original WellboreWellbore Classification:         AL - 12/27/2023
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:9/5/2022
Proposed Top PZ Location:Sec:32 Twp: 6N 61W Footage: 470 FSL  546 FEL
Bottom Hole Location:Sec:29 Twp: 6N 61W Footage: 470 FNL  535 FEL
Proposed Depth/Form:16308 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 407-2718 , Unit Acreage: 1280, Drill Unit: 6N-61W S.29&32 ALL
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 697, Top: 0 ft., Bottom: 1500 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 16308 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2643, Top: , Bottom: 16308 ft.
Wellbore Completed
Completion Date:N/A
Measured TD:Measured PB depth:
True Vertical TD:True Vertical PB depth:
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
