Wellbore #00 Wellbore Classification: OW Status: PR - 2/15/2026 Measured TD: 16331 ft. Vertical TD: 6302 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/15/2026 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 10/24/2025 | | Proposed Top PZ Location: | Sec:32 Twp: 6N 61W | Footage: 475 FNL 1925 FWL | | Bottom Hole Location: | Sec:29 Twp: 6N 61W | Footage: 480 FNL 1925 FWL | | Proposed Depth/Form: | 16161 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2718 , Unit Acreage: 1280, Drill Unit: T6N R61W SEC 29 & 32 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 95 ft., Weight: 37 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 95 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1725 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 721, Top: 0 ft., Bottom: 1725 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 16161 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2366, Top: 1725 ft., Bottom: 16161 ft. |
| | |
| Wellbore Completed | | Completion Date: | 8/11/2025 | | Spud Date: | 12/6/2023 | Spud Date Is: | ACTUAL | | Measured TD: | 16331 ft. | Measured PB depth: | 16327 ft. | | True Vertical TD: | 6302 ft. | True Vertical PB depth: | 6302 ft. | | Top PZ Location: | Sec:32 Twp: 6N 61W | Footage: 580 FSL 1893 FWL | | Bottom Hole Location: | Sec:29 Twp: 6N 61W | Footage: 461 FNL 1927 FWL | | Log Types: | No logs ran | | Log Types: | CBL, MWD/LWD, (RES on 123-51210). | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 95 ft., Weight: 36.95 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 95 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1725 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 721, Top: 0 ft., Bottom: 1725 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 16327 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2585, Top: 1300 ft., Bottom: 16327 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3367 ft. | | N | N | | SUSSEX | 3898 ft. | | N | N | | SHANNON | 4484 ft. | | N | N | | SHARON SPRINGS | 6146 ft. | | N | N | | NIOBRARA | 6291 ft. | | N | N |
Formation NBRR Formation Classification: LO Status: PR - 2/15/2026 Interval Top: 6822 ft. Interval Bottom: 16299 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 2/4/2026 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/2/2025 | Treatment End Date: | 11/15/2025 | | Treatment Summary: | Niobrara Frac'd with 54 stage plug and perf:
14499969 total pounds proppant pumped: 14499969 pounds 100 mesh;
502150 total bbls fluid pumped: 471423 bbls gelled fluid; 0 bbls fresh water,30079 bbls produced water; 648 bbls 15% HCl Acid.
| | Total fluid used in treatment (bbls): | 502150 | Max pressure during treatment (psi): | 8682 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 54 | | Total acid used in treatment (bbls): | 648 | Min frac gradient (psi/ft): | 0.86 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 0 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 14499969 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6435 ft. | | Tubing Packer Depth: | 6433 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/15/2026 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 816 | | BBLS_OIL | 126 | | BTU_GAS | 1300 | | CALC_BBLS_H2O | 816 | | CALC_BBLS_OIL | 126 | | CALC_GOR | 675 | | CALC_MCF_GAS | 85 | | CASING_PRESS | 56 | | GRAVITY_OIL | 38 | | MCF_GAS | 85 | | TUBING_PRESS | 667 |
| | Perforation Data: | | Interval Top: | 6822 ft. | # Of Holes: | 3378 | | Interval Bottom: | 16299 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 0 |
| Total Gas Produced (MCF) | 0 |
| GOR | |
| GOR Determination | |
| Average BOE per Day | 0.000 |
| Average MCFE per Day | 0.000 |
| Federal Financial Assurance | i | |
|
|
