COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-50372		Well Classification: OW Status: WO - 1/1/2025
Well Name/No:Fox Creek 12-63 #25-1-3
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:BISON IV OPERATING LLC - 10670
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:OG-108612
Facility Status:WOStatus Date1/1/2025
FacilityID:466601LocationID:466299
County:WELD #123Location:SWSE 25 12N63W 6
Field:HEREFORD - #34200Elevation:5399 ft.
Basin:DENVER (DJ) BASIN
Planned Location:931FSL  1470 FELLat/Long: 40.975921 / -104.376968Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.975921 / -104.376968Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: WO - 7/1/2024             Measured TD: 1535 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        WO - 7/1/2024
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:9/21/2027
Proposed Top PZ Location:Sec:36 Twp: 12N 63W Footage: 150 FNL  1800 FWL
Bottom Hole Location:Sec:1 Twp: 11N 63W Footage: 50 FSL  1800 FWL
Proposed Depth/Form:18605 ft.
Surface Mineral Owner Same:No
Mineral Owner:STATESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 421-121 , Unit Acreage: 1280, Drill Unit: T12N R63W Sec 36: AL
Casing:String Type: CONDUCTOR, Hole Size: 20 in., Size: 16.5 in., Top: 0 ft., Depth: 97 ft., Weight: 85 , Citings Type: PLANNED
Cement:Sacks: 78, Top: 0 ft., Bottom: 97 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1534 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 480, Top: 0 ft., Bottom: 1534 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18605 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2022, Top: 1300 ft., Bottom: 18605 ft.
Casing:String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6800 ft., Depth: 17841 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: 561, Top: 6800 ft., Bottom: 17841 ft.
Wellbore Completed
Completion Date:1/30/2020
Spud Date:1/30/2020Spud Date Is:ACTUAL
Measured TD:1535 ft.Measured PB depth:1535 ft.
True Vertical TD:True Vertical PB depth:
Bottom Hole Location:Sec:1 Twp: 11N 63WFootage: 50 FSL  1800 FWL
Log Types:
Casing:String Type: CONDUCTOR, Hole Size: 20 in., Size: 16.5 in., Top: 0 ft., Depth: 97 ft., Weight: 85 , Citings Type: ACTUAL
Cement:Sacks: 78, Top: 0 ft., Bottom: 97 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1534 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 480, Top: 0 ft., Bottom: 1534 ft., Determination Method: VISU
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
