Wellbore #00 Wellbore Classification: OW Status: PR - 5/21/2023 Measured TD: 14811 ft. Vertical TD: 6299 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 5/21/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/7/2024 | | Proposed Top PZ Location: | Sec:13 Twp: 9N 60W | Footage: 2340 FSL 990 FWL | | Bottom Hole Location: | Sec:24 Twp: 9N 60W | Footage: 214 FSL 1061 FWL | | Proposed Depth/Form: | 14981 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-1317 , Unit Acreage: 960, Drill Unit: S2 Sec 13, All Sec 2 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 92, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1771 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 481, Top: 0 ft., Bottom: 1771 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 14981 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 1915, Top: 0 ft., Bottom: 14981 ft. |
| | |
| Wellbore Completed | | Completion Date: | 10/3/2022 | | Spud Date: | 8/25/2022 | Spud Date Is: | ACTUAL | | Measured TD: | 14811 ft. | Measured PB depth: | 14726 ft. | | True Vertical TD: | 6299 ft. | True Vertical PB depth: | 6299 ft. | | Top PZ Location: | Sec:13 Twp: 9N 60W | Footage: 2311 FSL 1003 FWL | | Bottom Hole Location: | Sec:24 Twp: 9N 60W | Footage: 300 FSL 1136 FWL | | Log Types: | MWD/LWD, CBL, RES run on Rohn Fed 1324 16H 05-123-49539-00 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: ACTUAL | | Cement: | Sacks: 90, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1833 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 857, Top: 0 ft., Bottom: 1833 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 14811 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 1752, Top: 2608 ft., Bottom: 14811 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | FOX HILLS BASE | 0 ft. | 500 ft. | | | | PIERRE | 1186 ft. | | | | | PARKMAN | 3734 ft. | | | | | SUSSEX | 4277 ft. | | | | | SHANNON | 4794 ft. | | | | | SHARON SPRINGS | 6802 ft. | | | | | NIOBRARA | 6938 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 5/21/2023 Interval Top: 7320 ft. Interval Bottom: 14633 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 5/5/2023 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 3/25/2023 | Treatment End Date: | 4/3/2023 | | Treatment Summary: | FR Water 318,316 bbl, Treated Water 6,973 bbl, Fresh Water 919 bbl, (13,700,730 gals), 28% HCL 307 bbl. Proppant:100 Mesh 2,429,885 lbs, 40/70 white sand: 15,890,180 lbs. Flowback is measured by strapping a flowback tank every hour during initial flowback and from tank gauges during permanent facility flowback | | Total fluid used in treatment (bbls): | 326515 | Max pressure during treatment (psi): | 10407 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 36 | | Total acid used in treatment (bbls): | 307 | Min frac gradient (psi/ft): | 0.84 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 4212 | | Fresh water used in treatment (bbls): | 326208 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 18320065 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6756 ft. | | Tubing Packer Depth: | 6737 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 5/21/2023 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 519 | | BBLS_OIL | 469 | | BTU_GAS | 1515 | | CALC_BBLS_H2O | 519 | | CALC_BBLS_OIL | 469 | | CALC_GOR | 17 | | CALC_MCF_GAS | 9 | | GRAVITY_OIL | 36 | | MCF_GAS | 9 | | TUBING_PRESS | 715 |
| | Perforation Data: | | Interval Top: | 7320 ft. | # Of Holes: | 1332 | | Interval Bottom: | 14633 ft. | Hole Size: | 0.36 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 18749 |
| Total Gas Produced (MCF) | 42429 |
| GOR | 2263 |
| GOR Determination | BOE |
| Average BOE per Day | 69.583 |
| Average MCFE per Day | 403.573 |
| Federal Financial Assurance | i | Y |
|
|
