Wellbore #00 Wellbore Classification: OW Status: PR - 12/31/2021 Measured TD: 15100 ft. Vertical TD: 6847 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 12/31/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 10/28/2024 | | Proposed Top PZ Location: | Sec:8 Twp: 3N 64W | Footage: 200 FNL 350 FEL | | Bottom Hole Location: | Sec:17 Twp: 3N 64W | Footage: 2450 FNL 350 FEL | | Proposed Depth/Form: | 15107 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 960, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 173, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1850 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 633, Top: 0 ft., Bottom: 1850 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 15107 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 1668, Top: , Bottom: 15107 ft. |
| | |
| Wellbore Completed | | Completion Date: | 10/24/2020 | | Spud Date: | 10/20/2020 | Spud Date Is: | ACTUAL | | Measured TD: | 15100 ft. | Measured PB depth: | 15043 ft. | | True Vertical TD: | 6847 ft. | True Vertical PB depth: | 6847 ft. | | Top PZ Location: | Sec:8 Twp: 3N 64W | Footage: 218 FNL 351 FEL | | Bottom Hole Location: | Sec:17 Twp: 3N 64W | Footage: 2449 FNL 327 FEL | | Log Types: | CBL, MWD/LWD, NEU (IND in 123-22594) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 110 ft., Weight: 36.94 , Citings Type: ACTUAL | | Cement: | Sacks: 64, Top: 0 ft., Bottom: 110 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1927 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 638, Top: 0 ft., Bottom: 1927 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 15091 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 1770, Top: 1915 ft., Bottom: 15091 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3823 ft. | | | | | SUSSEX | 4310 ft. | | | | | SHANNON | 5055 ft. | | | | | TEEPEE BUTTES | 6255 ft. | | | | | SHARON SPRINGS | 7018 ft. | | | | | NIOBRARA | 7101 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 12/31/2021 Interval Top: 7583 ft. Interval Bottom: 14953 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 12/22/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/2/2021 | Treatment End Date: | 11/19/2021 | | Treatment Summary: | Niobrara completed with 130 bbls 28% HCL, 421,865 bbls slurry, 1,198,418 lb 100 mesh, 11,571,150 lb 40/70. | | Total fluid used in treatment (bbls): | 421995 | Max pressure during treatment (psi): | 8178 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 31 | | Total acid used in treatment (bbls): | 130 | Min frac gradient (psi/ft): | 0.92 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 421865 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 12769568 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7383 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 12/31/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 775 | | BBLS_OIL | 95 | | BTU_GAS | 1322 | | CALC_BBLS_H2O | 775 | | CALC_BBLS_OIL | 95 | | CALC_GOR | 3516 | | CALC_MCF_GAS | 334 | | CASING_PRESS | 3058 | | GRAVITY_OIL | 42 | | MCF_GAS | 334 | | TUBING_PRESS | 1774 |
| | Perforation Data: | | Interval Top: | 7583 ft. | # Of Holes: | 984 | | Interval Bottom: | 14953 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 27981 |
| Total Gas Produced (MCF) | 181241 |
| GOR | 6477 |
| GOR Determination | BOE |
| Average BOE per Day | 162.354 |
| Average MCFE per Day | 941.660 |
| Federal Financial Assurance | i | |
|
|
