COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISOld GIS Map Old GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-48299		Well Classification: OW Status: PR - 4/14/2026
Well Name/No:Dream Weaver North #3B-21H-N268
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:CRESTONE PEAK RESOURCES OPERATING LLC - 10633
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date4/14/2026
FacilityID:458258LocationID:457515
Municipality/County:FREDERICK / WELD #123Location:SESW 21 2N68W 6
Field:WATTENBERG - #90750Elevation:4901 ft.
Basin:DENVER (DJ) BASIN
Planned Location:1148FSL  1785 FWLLat/Long: 40.120037 / -105.011337Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.120040 / -105.011340Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 12/30/2020
End Date: 1/15/2021
Reported: 2/8/2021
Days to report: 24
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: WO - 1/1/2020             Measured TD: 19922 ft.    Vertical TD: 7422 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        WO - 1/1/2020
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:10/18/2020
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1030 FSL  410 FWL
Bottom Hole Location:Sec:9 Twp: 2N 68W Footage: 2180 FSL  480 FWL
Proposed Depth/Form:19884 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 560, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 78, Top: 0 ft., Bottom: 98 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2194 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 849, Top: 0 ft., Bottom: 2194 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19884 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2858, Top: , Bottom: 19884 ft.
Wellbore Completed
Completion Date:10/23/2019
Spud Date:8/15/2019Spud Date Is:ACTUAL
Measured TD:19922 ft.Measured PB depth:3975 ft.
True Vertical TD:7422 ft.True Vertical PB depth:3881 ft.
Bottom Hole Location:Sec:16 Twp: 2N 68WFootage: 2178 FSL  363 FWL
Log Types:MWD, MUD, Surface MUD (IND in 123-20125)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft., Determination Method: VISU
Casing:String Type: OPEN HOLE, Hole Size: 8.5 in., Size: , Top: 2280 ft., Depth: 19922 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: , Bottom: , Determination Method:
Additional Cement:String Type: OPEN HOLE , Top: 3841 ft., Depth: 4396 ft., Bottom: 4400 ft., Sacks: 217, Method:
Additional Cement:String Type: OPEN HOLE , Top: 4450 ft., Depth: 4923 ft., Bottom: 4923 ft., Sacks: 184, Method:
FormationInterval TopLog BottomCoredDSTs
SUSSEX4406 ft.NN
SHANNON4961 ft.NN
SHARON SPRINGS7380 ft.NN
NIOBRARA7467 ft.NN
FORT HAYS7936 ft.NN
CODELL7995 ft.NN
CARLILE8082 ft.NN
  No formation data to display.

Sidetrack #01             Wellbore Classification: OW             Status: EP - 10/23/2021             Measured TD: 6800 ft.    Vertical TD: 6624 ft.

 Wellbore Data for Sidetrack #01Wellbore Classification: OW        EP - 10/23/2021
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:10/23/2021
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1030 FSL  410 FWL
Bottom Hole Location:Sec:9 Twp: 2N 68W Footage: 2180 FSL  480 FWL
Proposed Depth/Form:19884 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 560, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19884 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2858, Top: , Bottom: 19884 ft.
Wellbore Completed
Completion Date:11/4/2019
Spud Date:8/15/2019Spud Date Is:ACTUAL
Measured TD:6800 ft.Measured PB depth:4111 ft.
True Vertical TD:6624 ft.True Vertical PB depth:4012 ft.
Bottom Hole Location:Sec:21 Twp: 2N 68WFootage: 315 FSL  578 FWL
Log Types:MWD/LWD, MUD, SONIC (IND in 123-20125)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft., Determination Method: VISU
Casing:String Type: OPEN HOLE, Hole Size: 8.5 in., Size: , Top: 2280 ft., Depth: 6800 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: , Bottom: , Determination Method:
Additional Cement:String Type: OPEN HOLE , Top: 4111 ft., Depth: 4700 ft., Bottom: 4700 ft., Sacks: 217, Method:
Additional Cement:String Type: OPEN HOLE , Top: 4740 ft., Depth: 5300 ft., Bottom: 5300 ft., Sacks: 217, Method:
Additional Cement:String Type: OPEN HOLE , Top: 6128 ft., Depth: 6800 ft., Bottom: 6800 ft., Sacks: 217, Method:
  No formation data to display.

Sidetrack #02             Wellbore Classification: OW             Status: EP - 12/9/2021             Measured TD: 5150 ft.    Vertical TD: 5022 ft.

 Wellbore Data for Sidetrack #02Wellbore Classification: OW        EP - 12/9/2021
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:12/9/2021
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1030 FSL  410 FWL
Bottom Hole Location:Sec:9 Twp: 2N 68W Footage: 2180 FSL  480 FWL
Proposed Depth/Form:19884 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 560, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19884 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2858, Top: , Bottom: 19884 ft.
Wellbore Completed
Completion Date:12/23/2019
Spud Date:8/15/2019Spud Date Is:ACTUAL
Measured TD:5150 ft.Measured PB depth:4755 ft.
True Vertical TD:5022 ft.True Vertical PB depth:4636 ft.
Bottom Hole Location:Sec:21 Twp: 2N 68WFootage: 538 FSL  905 FWL
Log Types:MUD (IND in 123-15493)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft., Determination Method: VISU
Casing:String Type: OPEN HOLE, Hole Size: 8.5 in., Size: , Top: 2280 ft., Depth: 5150 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: , Bottom: , Determination Method:
Additional Cement:String Type: OPEN HOLE , Top: 4755 ft., Depth: 5150 ft., Bottom: 5150 ft., Sacks: 131, Method:
  No formation data to display.

Sidetrack #03             Wellbore Classification: OW             Status: EP - 12/25/2021             Measured TD: 4960 ft.    Vertical TD: 4837 ft.

 Wellbore Data for Sidetrack #03Wellbore Classification: OW        EP - 12/25/2021
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:12/25/2021
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1030 FSL  410 FWL
Bottom Hole Location:Sec:9 Twp: 2N 68W Footage: 2180 FSL  480 FWL
Proposed Depth/Form:19884 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 560, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19884 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2858, Top: , Bottom: 19884 ft.
Wellbore Completed
Completion Date:12/26/2019
Spud Date:8/15/2019Spud Date Is:ACTUAL
Measured TD:4960 ft.Measured PB depth:4556 ft.
True Vertical TD:4837 ft.True Vertical PB depth:4443 ft.
Bottom Hole Location:Sec:21 Twp: 2N 68WFootage: 567 FSL  939 FWL
Log Types:MUD (IND in 123-15493)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft., Determination Method: VISU
Casing:String Type: OPEN HOLE, Hole Size: 8.5 in., Size: , Top: 2280 ft., Depth: 4960 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: , Bottom: , Determination Method:
Additional Cement:String Type: OPEN HOLE , Top: 4556 ft., Depth: 4960 ft., Bottom: 4960 ft., Sacks: 154, Method:
  No formation data to display.

Sidetrack #04             Wellbore Classification: OW             Status: PR - 4/14/2026             Measured TD: 19922 ft.    Vertical TD: 7466 ft.

 Wellbore Data for Sidetrack #04Wellbore Classification: OW        PR - 4/14/2026
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:12/26/2021
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1030 FSL  410 FWL
Bottom Hole Location:Sec:9 Twp: 2N 68W Footage: 2180 FSL  480 FWL
Proposed Depth/Form:19884 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CARL , Formation: CARLILE , Order: , Unit Acreage: 800, Drill Unit: GWA
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 800, Drill Unit: GWA
Formation And Spacing:Code: FTHYS , Formation: FORT HAYS , Order: , Unit Acreage: 800, Drill Unit: GWA
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 800, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19884 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2858, Top: , Bottom: 19884 ft.
Wellbore Completed
Completion Date:1/5/2020
Spud Date:8/14/2019Spud Date Is:ACTUAL
Measured TD:19922 ft.Measured PB depth:19893 ft.
True Vertical TD:7466 ft.True Vertical PB depth:7466 ft.
Top PZ Location:Sec:21 Twp: 2N 68WFootage: 1318 FSL  368 FWL
Bottom Hole Location:Sec:33 Twp: 2N 68WFootage: 2178 FSL  363 FWL
Log Types:MUD (IND in 123-20125)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2280 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 896, Top: 0 ft., Bottom: 2280 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19907 ft., Weight: 20 , Citings Type: ACTUAL
Cement:Sacks: 2533, Top: 2470 ft., Bottom: 19922 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
SUSSEX4406 ft.NN
SHANNON4961 ft.NN
SHARON SPRINGS7380 ft.NN
NIOBRARA7467 ft.NN
FORT HAYS7936 ft.NN
CODELL7995 ft.NN
CARLILE8082 ft.NN

Formation NBRR                     Formation Classification:  OW                     Status:  CM - 4/14/2026                 Interval Top: 16647 ft.    Interval Bottom: 16952 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:1/15/2021Choke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2020Treatment End Date:1/15/2021
Treatment Summary:Niobrara: 16647-16952
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NBRR.
Perforation Data:
Interval Top:16647 ft.# Of Holes:24
Interval Bottom:16952 ft.Hole Size:0.42 in.

Formation FTHYS                   Formation Classification:  OW                   Status:  CM - 4/14/2026                 Interval Top: 16622 ft.    Interval Bottom: 17049 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:4/2/2021Choke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2021Treatment End Date:1/15/2021
Treatment Summary:Ft Hays: 16622-16646, 16953-17049
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2020Treatment End Date:1/15/2021
Treatment Summary:16622 - 16646; 16953 - 17049
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:16622 ft.# Of Holes:22
Interval Bottom:17049 ft.Hole Size:0.42 in.

Formation CODL                     Formation Classification:  OW                     Status:  CM - 4/14/2026                 Interval Top: 8765 ft.    Interval Bottom: 19676 ft.

 Completed Information for Formation CODELL
1st Production Date:4/2/2021Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2021Treatment End Date:1/15/2021
Treatment Summary:Codell: 8765-11887, 11908-16573, 17050-19676
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2020Treatment End Date:1/15/2021
Treatment Summary:8765 - 11887; 11908 - 16573; 17050 - 19676
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:8765 ft.# Of Holes:808
Interval Bottom:19676 ft.Hole Size:0.42 in.

Formation CARL                     Formation Classification:  OW                     Status:  CM - 4/14/2026                 Interval Top: 8460 ft.    Interval Bottom: 19884 ft.

 Completed Information for Formation CARLILE
1st Production Date:4/2/2021Choke Size:
Formation Name:CARLILECommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2020Treatment End Date:1/15/2021
Treatment Summary:8460 - 8716; 11888 - 11907; 19677 - 19884
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CARL.
Perforation Data:
Interval Top:8460 ft.# Of Holes:53
Interval Bottom:19884 ft.Hole Size:0.42 in.

Formation NFCC                     Formation Classification:  OW                     Status:  PR - 4/14/2026                 Interval Top: 8460 ft.    Interval Bottom: 19884 ft.

 Completed Information for Formation NIOBRARA-FORT HAYS-CODELL-CARLILE
1st Production Date:4/2/2021Choke Size:
Formation Name:NIOBRARA-FORT HAYS-CODELL-CARLILECommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/30/2020Treatment End Date:1/15/2021
Treatment Summary:39 stage plug and perf: 6898395# sand; 283023 total bbls fluid: 6 bbls acid; 32 bbls recycled water; 282985 bbls fresh water
Total fluid used in treatment (bbls):283023Max pressure during treatment (psi):8799
Total gas used in treatment (mcf):0Fluid density (lbs/gal):8.34
Type Of gas:Number Of staged intervals:39
Total acid used in treatment (bbls):6Min frac gradient (psi/ft):0.87
Recycled water used in treatment (bbls):32Total flowback volume recovered (bbls):5946
Fresh water used in treatment (bbls):282985Disposition method For flowback:DISPOSAL
Total proppant used (lbs):6898395Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:N/ATest Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 630
BBLS_OIL 225
BTU_GAS 1261
CALC_BBLS_H2O 630
CALC_BBLS_OIL 225
CALC_GOR 2747
CALC_MCF_GAS 618
GRAVITY_OIL 50
MCF_GAS 618
Perforation Data:
Interval Top:8460 ft.# Of Holes:907
Interval Bottom:19884 ft.Hole Size:0.42 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
March 2025 - February 2026i
Total Oil Produced (Barrels)11495
Total Gas Produced (MCF)83812
GOR7291
GOR DeterminationBOE
Average BOE per Day71.142
Average MCFE per Day412.614

 Federal Financial Assurance  i

 Tribal Well  i No
