Wellbore #00 Wellbore Classification: OW Status: PR - 4/5/2021 Measured TD: 19625 ft. Vertical TD: 7290 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/5/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 10/18/2020 | | Proposed Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 1452 FSL 569 FWL | | Bottom Hole Location: | Sec:9 Twp: 2N 68W | Footage: 2168 FSL 470 FWL | | Proposed Depth/Form: | 19610 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 400, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 78, Top: 0 ft., Bottom: 98 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2185 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 846, Top: 0 ft., Bottom: 2185 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19610 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2816, Top: , Bottom: 19610 ft. |
| | |
| Wellbore Completed | | Completion Date: | 11/12/2019 | | Spud Date: | 8/15/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 19625 ft. | Measured PB depth: | 19596 ft. | | True Vertical TD: | 7290 ft. | True Vertical PB depth: | 7290 ft. | | Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 1452 FSL 569 FWL | | Bottom Hole Location: | Sec:9 Twp: 2N 68W | Footage: 2168 FSL 470 FWL | | Log Types: | MWD/LWD (IND in 123-20125) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 122 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 95, Top: 0 ft., Bottom: 122 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2243 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 883, Top: 0 ft., Bottom: 2243 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19610 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 3440, Top: 2066 ft., Bottom: 19625 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4315 ft. | | N | N | | SHANNON | 4932 ft. | | N | N | | SHARON SPRINGS | 7413 ft. | | N | N | | NIOBRARA | 7575 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 4/5/2021 Interval Top: 8310 ft. Interval Bottom: 19587 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 4/5/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/30/2020 | Treatment End Date: | 1/30/2021 | | Treatment Summary: | 428154 bbls of water, 180 bbls of additives (FRP-22G, Bardac 2250M, Dixichlor Max, Plexcide P5W, T-Chlor 12.5, SAFE-BFH-2, XLS-3Z, BHL-68W, ACI-97, ASF-67) and 42 bbl HCL in a 59 stage frac with 34938 lbs of DFR-1X, 6256 lbs of PGA-4045, and 6915220 lbs of silica quartz proppant. Oil and water are metered from flowback equipment. The daily water volumes are periodically checked against trucked volumes. All meters are calibrated before use on every pad.
| | Total fluid used in treatment (bbls): | 428726 | Max pressure during treatment (psi): | 8911 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 59 | | Total acid used in treatment (bbls): | 42 | Min frac gradient (psi/ft): | 0.93 | | Recycled water used in treatment (bbls): | 350 | Total flowback volume recovered (bbls): | 4457 | | Fresh water used in treatment (bbls): | 428334 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6915220 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7536 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/5/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 448 | | BBLS_OIL | 772 | | BTU_GAS | 1261 | | CALC_BBLS_H2O | 448 | | CALC_BBLS_OIL | 772 | | CALC_GOR | 1514 | | CALC_MCF_GAS | 1169 | | CASING_PRESS | 2450 | | GRAVITY_OIL | 50 | | MCF_GAS | 1169 | | TUBING_PRESS | 1650 |
| | Perforation Data: | | Interval Top: | 8310 ft. | # Of Holes: | 1398 | | Interval Bottom: | 19587 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 12135 |
| Total Gas Produced (MCF) | 215956 |
| GOR | 17796 |
| GOR Determination | MCFE |
| Average BOE per Day | 135.396 |
| Average MCFE per Day | 785.296 |
| Federal Financial Assurance | i | |
|
|
