Facility Detail

COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-48291		Well Classification: LO Status: SO - 11/1/2020
Well Name/No:Dream Weaver North #3H-21H-N268
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:CRESTONE PEAK RESOURCES OPERATING LLC - 10633
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:SOStatus Date11/1/2020
FacilityID:458249LocationID:457515
Municipality/County:FREDERICK / WELD #123Location:SESW 21 2N68W 6
Field:WATTENBERG - #90750Elevation:4901 ft.
Basin:DENVER (DJ) BASIN
Planned Location:1086FSL  1824 FWLLat/Long: 40.119868 / -105.011196Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.119870 / -105.011200Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: LO             Status: SO - 11/1/2020             Measured TD: 2207 ft.    Vertical TD: 2198 ft.

 Wellbore Data for Original WellboreWellbore Classification: LO        SO - 11/1/2020
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:10/18/2020
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1044 FSL  1754 FWL
Bottom Hole Location:Sec:21 Twp: 2N 68W Footage: 938 FSL  1820 FWL
Proposed Depth/Form:19530 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 800, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 78, Top: 0 ft., Bottom: 98 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2160 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 837, Top: 0 ft., Bottom: 2160 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19530 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2804, Top: , Bottom: 19530 ft.
Wellbore Completed
Completion Date:8/22/2019
Spud Date:8/21/2019Spud Date Is:ACTUAL
Measured TD:2207 ft.Measured PB depth:2146 ft.
True Vertical TD:2198 ft.True Vertical PB depth:2138 ft.
Bottom Hole Location:Sec:21 Twp: 2N 68WFootage: 938 FSL  1820 FWL
Log Types:
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 112 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 112 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2192 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 877, Top: 0 ft., Bottom: 2192 ft., Determination Method: VISU
  No formation data to display.
Primary Well Designation:
Noticed Inactive      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveYNoticed Date
04/04/2025
Defined Inactive (SO )YDefined Inactive
11/01/2020
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
December 2024 - November 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
