Wellbore #00 Wellbore Classification: OW Status: PR - 3/24/2021 Measured TD: 19832 ft. Vertical TD: 7425 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/24/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 10/18/2020 | | Proposed Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 460 FSL 1180 FWL | | Bottom Hole Location: | Sec:9 Twp: 2N 68W | Footage: 2187 FSL 1189 FWL | | Proposed Depth/Form: | 19785 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: , Unit Acreage: 800, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 78, Top: 0 ft., Bottom: 98 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2166 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 839, Top: 0 ft., Bottom: 2166 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19785 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2843, Top: , Bottom: 19785 ft. |
| | |
| Wellbore Completed | | Completion Date: | 12/1/2019 | | Spud Date: | 8/18/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 19832 ft. | Measured PB depth: | 19796 ft. | | True Vertical TD: | 7425 ft. | True Vertical PB depth: | 7425 ft. | | Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 460 FSL 1180 FWL | | Bottom Hole Location: | Sec:9 Twp: 2N 68W | Footage: 2187 FSL 1189 FWL | | Log Types: | MWD/LWD (IND in API 123-20125) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2228 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 883, Top: 0 ft., Bottom: 2228 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19810 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2459, Top: 2884 ft., Bottom: 19832 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4259 ft. | | N | N | | SHANNON | 4898 ft. | | N | N | | SHARON SPRINGS | 7245 ft. | | N | N | | NIOBRARA | 7346 ft. | | N | N | | FORT HAYS | 7748 ft. | | N | N | | CARLILE | 7781 ft. | | N | N | | CODELL | 7798 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: CM - 11/8/2021 Interval Top: 16685 ft. Interval Bottom: 16726 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 4/5/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/18/2021 | Treatment End Date: | 1/30/2021 | | Treatment Summary: | Niobrara: 16685-16726 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 16685 ft. | # Of Holes: | 944 | | Interval Bottom: | 16726 ft. | Hole Size: | 0.42 in. |
|
Formation CARL Formation Classification: OW Status: CM - 11/8/2021 Interval Top: 7881 ft. Interval Bottom: 11021 ft.| Completed Information for Formation CARLILE | | 1st Production Date: | 7/5/2021 | Choke Size: | | | Formation Name: | CARLILE | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/18/2021 | Treatment End Date: | 1/30/2021 | | Treatment Summary: | Carlile: 7881-11021 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CARL. |
| | Perforation Data: | | Interval Top: | 7881 ft. | # Of Holes: | 944 | | Interval Bottom: | 11021 ft. | Hole Size: | 0.42 in. |
|
Formation CODL Formation Classification: OW Status: CM - 11/8/2021 Interval Top: 7798 ft. Interval Bottom: 19672 ft.| Completed Information for Formation CODELL | | 1st Production Date: | 4/5/2021 | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/18/2021 | Treatment End Date: | 1/30/2021 | | Treatment Summary: | Codell: 7798-7880, 11022-13236, 13261-16324, 16978-19672 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 7798 ft. | # Of Holes: | 944 | | Interval Bottom: | 19672 ft. | Hole Size: | 0.42 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 11/8/2021 Interval Top: 7758 ft. Interval Bottom: 16977 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | 4/5/2021 | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/18/2021 | Treatment End Date: | 1/30/2021 | | Treatment Summary: | Ft Hays: 7758-7797, 13237-13260, 16727-16977 | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 7758 ft. | # Of Holes: | 944 | | Interval Bottom: | 16977 ft. | Hole Size: | 0.42 in. |
|
Formation NFCC Formation Classification: OW Status: PR - 3/24/2021 Interval Top: 7758 ft. Interval Bottom: 19672 ft.| Completed Information for Formation NIOBRARA-FORT HAYS-CODELL-CARLILE | | 1st Production Date: | 4/5/2021 | Choke Size: | | | Formation Name: | NIOBRARA-FORT HAYS-CODELL-CARLILE | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 1/18/2021 | Treatment End Date: | 1/30/2021 | | Treatment Summary: | 273416 bbls of water, 143 bbls of additives (FRP-22G, Bardac 2250M, Dixichlor Max, Plexcide P5W, T-Chlor 12.5, SAFE-BFH-2, XLS-3Z, BHL-68W, ACI-97, ASF-67) and 18 bbl HCL in a 40 stage frac with 26598 lbs of DFR-1X, 4992 lbs of PGA-4045, and 6932465 lbs of silica quartz proppant. Oil and water are metered from flowback equipment. The daily water volumes are periodically checked against trucked volumes. All meters are calibrated before use on every pad.
| | Total fluid used in treatment (bbls): | 273582 | Max pressure during treatment (psi): | 8939 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 40 | | Total acid used in treatment (bbls): | 18 | Min frac gradient (psi/ft): | 0.93 | | Recycled water used in treatment (bbls): | 5 | Total flowback volume recovered (bbls): | 12846 | | Fresh water used in treatment (bbls): | 273559 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6932465 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7746 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/24/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 492 | | BBLS_OIL | 309 | | BTU_GAS | 1261 | | CALC_BBLS_H2O | 492 | | CALC_BBLS_OIL | 309 | | CALC_GOR | 1896 | | CALC_MCF_GAS | 586 | | CASING_PRESS | 2400 | | GRAVITY_OIL | 50 | | MCF_GAS | 586 | | TUBING_PRESS | 1675 |
| | Perforation Data: | | Interval Top: | 7758 ft. | # Of Holes: | 944 | | Interval Bottom: | 19672 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 9554 |
| Total Gas Produced (MCF) | 224459 |
| GOR | 23493 |
| GOR Determination | MCFE |
| Average BOE per Day | 132.152 |
| Average MCFE per Day | 766.466 |
| Federal Financial Assurance | i | |
|
|
