COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-48005		Well Classification: OW Status: PR - 3/1/2021
Well Name/No:Dream Weaver South #3B-21H-N268
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:CRESTONE PEAK RESOURCES OPERATING LLC - 10633
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date3/1/2021
FacilityID:457612LocationID:457515
Municipality/County:FREDERICK / WELD #123Location:SESW 21 2N68W 6
Field:WATTENBERG - #90750Elevation:4901 ft.
Basin:DENVER (DJ) BASIN
Planned Location:1035FSL  1857 FWLLat/Long: 40.119727 / -105.011080Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.119730 / -105.011080Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 11/19/2020
End Date: 12/7/2020
Reported: 1/21/2021
Days to report: 45
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 3/1/2021             Measured TD: 15230 ft.    Vertical TD: 7581 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 3/1/2021
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:9/24/2020
Proposed Top PZ Location:Sec:21 Twp: 2N 68W Footage: 1304 FSL  446 FWL
Bottom Hole Location:Sec:33 Twp: 2N 68W Footage: 709 FNL  515 FWL
Proposed Depth/Form:19364 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: , Unit Acreage: 640, Drill Unit: GWA
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED
Cement:Sacks: 78, Top: 0 ft., Bottom: 98 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2195 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 850, Top: 0 ft., Bottom: 2195 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19364 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2779, Top: , Bottom: 19364 ft.
Wellbore Completed
Completion Date:3/31/2020
Spud Date:8/26/2019Spud Date Is:ACTUAL
Measured TD:15230 ft.Measured PB depth:15202 ft.
True Vertical TD:7581 ft.True Vertical PB depth:7581 ft.
Top PZ Location:Sec:21 Twp: 2N 68WFootage: 1304 FSL  446 FWL
Bottom Hole Location:Sec:33 Twp: 2N 68WFootage: 709 FNL  515 FWL
Log Types:Surface MUD, MUD, MWD/LWD (IND in API 123-20125)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2233 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 890, Top: 0 ft., Bottom: 2233 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 15216 ft., Weight: 20 , Citings Type: ACTUAL
Cement:Sacks: 1749, Top: 2270 ft., Bottom: 15230 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
SUSSEX4309 ft.NN
SHANNON4933 ft.NN
SHARON SPRINGS7327 ft.NN
NIOBRARA7448 ft.NN
FORT HAYS7872 ft.NN
CODELL7943 ft.NN

Formation NBRR                     Formation Classification:  OW                     Status:  CM - 12/9/2021                 Interval Top: 10439 ft.    Interval Bottom: 13724 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:3/17/2021Choke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:11/19/2020Treatment End Date:12/7/2020
Treatment Summary:Niobrara: 10439-10855, 10963-10995, 13658-13724
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NBRR.
Perforation Data:
Interval Top:10439 ft.# Of Holes:630
Interval Bottom:13724 ft.Hole Size:0.42 in.

Formation CODL                     Formation Classification:  OW                     Status:  CM - 12/9/2021                 Interval Top: 7943 ft.    Interval Bottom: 15079 ft.

 Completed Information for Formation CODELL
1st Production Date:3/17/2021Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:11/19/2020Treatment End Date:12/7/2020
Treatment Summary:Codell: 7943-10141, 12378-13657, 14012-15079
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:7943 ft.# Of Holes:630
Interval Bottom:15079 ft.Hole Size:0.42 in.

Formation FTHYS                   Formation Classification:  OW                   Status:  CM - 12/9/2021                 Interval Top: 7882 ft.    Interval Bottom: 13963 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:3/17/2021Choke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:11/19/2020Treatment End Date:12/7/2020
Treatment Summary:Ft Hays: 7882-7942, 10142-10438, 10856-10962, 10996-12377, 13725-13963
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:7882 ft.# Of Holes:630
Interval Bottom:13963 ft.Hole Size:0.42 in.

Formation NBFHC                   Formation Classification:  OW                   Status:  PR - 3/1/2021                  Interval Top: 7882 ft.    Interval Bottom: 15079 ft.

 Completed Information for Formation NIOBRARA-FT HAYS-CODELL
1st Production Date:3/17/2021Choke Size:
Formation Name:NIOBRARA-FT HAYS-CODELLCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:11/19/2020Treatment End Date:12/7/2020
Treatment Summary:178086 bbls of water, 87 bbls of additives (FRP-22G, Bardac 2250M, Bellacide 355, Dixichlor Max, SAFE-BFH-2, XLS-3Z, BHL-68W) and 0 bbl HCL in a 28 stage frac with 13,494 lbs of DFR-1X, 776 lbs of DFR-2S, 708 lbs of PGA-4045, 4551150 lbs of silica quartz proppant. Oil and water are metered from flowback equipment. The daily water volumes are periodically checked against trucked volumes. All meters are calibrated before use on every pad.
Total fluid used in treatment (bbls):182228Max pressure during treatment (psi):9024
Total gas used in treatment (mcf):Fluid density (lbs/gal):8.34
Type Of gas:Number Of staged intervals:28
Total acid used in treatment (bbls):0Min frac gradient (psi/ft):0.85
Recycled water used in treatment (bbls):4055Total flowback volume recovered (bbls):10855
Fresh water used in treatment (bbls):178173Disposition method For flowback:DISPOSAL
Total proppant used (lbs):4551150Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:2.375 in.Tubing Setting Depth:7766 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:3/1/2021Test Method:Flowing
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 535
BBLS_OIL 490
BTU_GAS 1270
CALC_BBLS_H2O 535
CALC_BBLS_OIL 490
CALC_GOR 1739
CALC_MCF_GAS 852
CASING_PRESS 2750
GRAVITY_OIL 50
MCF_GAS 852
TUBING_PRESS 1475
Perforation Data:
Interval Top:7882 ft.# Of Holes:630
Interval Bottom:15079 ft.Hole Size:0.42 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
December 2024 - November 2025i
Total Oil Produced (Barrels)12399
Total Gas Produced (MCF)191458
GOR15441
GOR DeterminationMCFE
Average BOE per Day124.413
Average MCFE per Day721.597

 Federal Financial Assurance  i

 Tribal Well  i No
