Wellbore #00 Wellbore Classification: OW Status: PR - 2/22/2021 Measured TD: 19068 ft. Vertical TD: 7404 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/22/2021 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/20/2020 | | Proposed Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 1349 FNL 2673 FWL | | Bottom Hole Location: | Sec:33 Twp: 2N 68W | Footage: 478 FSL 2585 FWL | | Proposed Depth/Form: | 19075 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 800, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 98 ft., Weight: 42.09 , Citings Type: PLANNED | | Cement: | Sacks: 78, Top: 0 ft., Bottom: 98 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2172 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 841, Top: 0 ft., Bottom: 2172 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19075 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2735, Top: , Bottom: 19075 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/12/2020 | | Spud Date: | 9/5/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 19068 ft. | Measured PB depth: | 19035 ft. | | True Vertical TD: | 7404 ft. | True Vertical PB depth: | 7404 ft. | | Top PZ Location: | Sec:21 Twp: 2N 68W | Footage: 1349 FNL 2673 FWL | | Bottom Hole Location: | Sec:33 Twp: 2N 68W | Footage: 478 FSL 2585 FWL | | Log Types: | MWD/LWD (IND in 123-20125) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 127 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 95, Top: 0 ft., Bottom: 127 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2240 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 982, Top: 0 ft., Bottom: 2240 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 19050 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2399, Top: 2352 ft., Bottom: 19050 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4287 ft. | | N | N | | SHANNON | 4902 ft. | | N | N | | SHARON SPRINGS | 7328 ft. | | N | N | | NIOBRARA | 7501 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 2/22/2021 Interval Top: 7511 ft. Interval Bottom: 19023 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/17/2021 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 11/22/2020 | Treatment End Date: | 12/22/2020 | | Treatment Summary: | 427400 bbls of water, 184 bbls of additives (FRP-22G, Bardac 2250M, Bellacide 355, Dixichlor Max, SAFE-BFH-2, XLS-3Z, BHL-68W, ACI-97, ASF-67) and 96 bbl HCL in a 61 stage frac with 29026 lbs of DFR-1X, 4281 lbs of DFR-2S, 785 lbs of PGA-4045, 2200 lbs of Calcium Chloride, 7613385 lbs of silica quartz proppant
Oil and water are metered from flowback equipment. The daily water volumes are periodically checked against trucked volumes. All meters are calibrated before use on every pad. | | Total fluid used in treatment (bbls): | 448336 | Max pressure during treatment (psi): | 9161 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 61 | | Total acid used in treatment (bbls): | 96 | Min frac gradient (psi/ft): | 0.86 | | Recycled water used in treatment (bbls): | 20656 | Total flowback volume recovered (bbls): | 15342 | | Fresh water used in treatment (bbls): | 427584 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 7613385 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7347 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/22/2021 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 545 | | BBLS_OIL | 678 | | BTU_GAS | 1270 | | CALC_BBLS_H2O | 545 | | CALC_BBLS_OIL | 678 | | CALC_GOR | 1499 | | CALC_MCF_GAS | 1016 | | CASING_PRESS | 2400 | | GRAVITY_OIL | 50 | | MCF_GAS | 1016 | | TUBING_PRESS | 1825 |
| | Perforation Data: | | Interval Top: | 7511 ft. | # Of Holes: | 1418 | | Interval Bottom: | 19023 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 14619 |
| Total Gas Produced (MCF) | 331305 |
| GOR | 22662 |
| GOR Determination | MCFE |
| Average BOE per Day | 196.506 |
| Average MCFE per Day | 1139.746 |
| Federal Financial Assurance | i | |
|
|
