Wellbore #00 Wellbore Classification: OW Status: PR - 3/6/2023 Measured TD: 18370 ft. Vertical TD: 6779 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/6/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/24/2020 | | Proposed Top PZ Location: | Sec:18 Twp: 2N 68W | Footage: 339 FSL 1059 FEL | | Bottom Hole Location: | Sec:18 Twp: 2N 68W | Footage: 339 FSL 1059 FEL | | Proposed Depth/Form: | 18523 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-2458 , Unit Acreage: 1440, Drill Unit: 6:S2;7:All;18:N2,SE | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 400, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18523 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2480, Top: , Bottom: 18523 ft. |
| | |
| Wellbore Completed | | Completion Date: | 9/28/2022 | | Spud Date: | 6/4/2020 | Spud Date Is: | ACTUAL | | Measured TD: | 18370 ft. | Measured PB depth: | 18359 ft. | | True Vertical TD: | 6779 ft. | True Vertical PB depth: | 6779 ft. | | Top PZ Location: | Sec:18 Twp: 2N 68W | Footage: 2117 FNL 1727 FWL | | Bottom Hole Location: | Sec:6 Twp: 2N 68W | Footage: 2178 FSL 1754 FWL | | Log Types: | | | Log Types: | CBL, MWD/LWD, (Triple Combination on 123-47175). | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 55 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1620 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 525, Top: 0 ft., Bottom: 1620 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 18359 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2855, Top: 250 ft., Bottom: 18359 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 4111 ft. | | N | N | | SUSSEX | 4624 ft. | | N | N | | SHANNON | 5190 ft. | | N | N | | SHARON SPRINGS | 7901 ft. | | N | N | | NIOBRARA | 7931 ft. | | N | N | | FORT HAYS | 8424 ft. | | N | N | | CODELL | 9084 ft. | | N | N | | CARLILE | 10046 ft. | | | | | GREENHORN | 16803 ft. | 17645 ft. | N | N |
Formation GRNHN Formation Classification: OW Status: PR - 3/6/2023 Interval Top: 16813 ft. Interval Bottom: 17636 ft.| Completed Information for Formation GREENHORN | | 1st Production Date: | 2/24/2023 | Choke Size: | | | Formation Name: | GREENHORN | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/17/2022 | Treatment End Date: | 1/2/2023 | | Treatment Summary: | Frac'd with Carlile-Codell-Fort Hays | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/6/2023 | Test Method: | flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 64 | | BBLS_OIL | 41 | | BTU_GAS | 1307 | | CALC_BBLS_H2O | 64 | | CALC_BBLS_OIL | 41 | | CALC_GOR | 2447 | | CALC_MCF_GAS | 100 | | CASING_PRESS | 2687 | | GRAVITY_OIL | 48 | | MCF_GAS | 100 | | TUBING_PRESS | 1767 |
| | Perforation Data: | | Interval Top: | 16813 ft. | # Of Holes: | 220 | | Interval Bottom: | 17636 ft. | Hole Size: | 0.35 in. |
|
Formation CARL Formation Classification: OW Status: CM - 4/20/2023 Interval Top: 10055 ft. Interval Bottom: 11402 ft.| Completed Information for Formation CARLILE | | 1st Production Date: | 2/24/2023 | Choke Size: | | | Formation Name: | CARLILE | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CARL. |
| | Perforation Data: | | Interval Top: | 10055 ft. | # Of Holes: | 305 | | Interval Bottom: | 11402 ft. | Hole Size: | 0.35 in. |
|
Formation CODL Formation Classification: OW Status: CM - 4/20/2023 Interval Top: 9098 ft. Interval Bottom: 18295 ft.| Completed Information for Formation CODELL | | 1st Production Date: | 2/24/2023 | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/17/2022 | Treatment End Date: | 1/2/2023 | | Treatment Summary: | Perforated Intervals: 9098'-9958'; 11424'-16799'; 17655'-18295'. | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 9098 ft. | # Of Holes: | 1259 | | Interval Bottom: | 18295 ft. | Hole Size: | 0.35 in. |
|
Formation CLCDFH Formation Classification: OW Status: PR - 3/6/2023 Interval Top: 8696 ft. Interval Bottom: 18295 ft.| Completed Information for Formation CARLILE-CODELL-FORT HAYS | | 1st Production Date: | 2/24/2023 | Choke Size: | | | Formation Name: | CARLILE-CODELL-FORT HAYS | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/17/2022 | Treatment End Date: | 1/2/2023 | | Treatment Summary: | Frac'd Fort Hays-Carlile-Codell-Greenhorn with 43 stage plug and perf;
6017155 total pounds proppant pumped: 5982732 pounds 40/70 mesh and 34423 pounds 100 mesh;
227324 total bbls fluid pumped: 209914 bbls gelled fluid, 17279 bbls fresh water and 131 bbls 15% HCl acid. | | Total fluid used in treatment (bbls): | 227324 | Max pressure during treatment (psi): | 9069 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 43 | | Total acid used in treatment (bbls): | 131 | Min frac gradient (psi/ft): | 0.83 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 17279 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6017155 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8567 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/6/2023 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 574 | | BBLS_OIL | 368 | | BTU_GAS | 1307 | | CALC_BBLS_H2O | 574 | | CALC_BBLS_OIL | 368 | | CALC_GOR | 2448 | | CALC_MCF_GAS | 901 | | CASING_PRESS | 2687 | | GRAVITY_OIL | 48 | | MCF_GAS | 901 | | TUBING_PRESS | 1767 |
| | Perforation Data: | | Interval Top: | 8696 ft. | # Of Holes: | 1672 | | Interval Bottom: | 18295 ft. | Hole Size: | 0.35 in. |
|
Formation FTHYS Formation Classification: OW Status: CM - 4/20/2023 Interval Top: 8696 ft. Interval Bottom: 10041 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | 2/24/2023 | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/17/2022 | Treatment End Date: | 1/2/2023 | | Treatment Summary: | Perforated Intervals: 8696'-9079'; 9976'-10041'. | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 8696 ft. | # Of Holes: | 108 | | Interval Bottom: | 10041 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 23376 |
| Total Gas Produced (MCF) | 324328 |
| GOR | 13874 |
| GOR Determination | BOE |
| Average BOE per Day | 217.349 |
| Average MCFE per Day | 1260.651 |
| Federal Financial Assurance | i | |
|
|
