COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-47476		Well Classification: OW Status: SO - 10/1/2022
Well Name/No:Rinn Valley West #18N-25-05C
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:EXTRACTION OIL & GAS INC - 10459
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:SOStatus Date10/1/2022
FacilityID:456272LocationID:455340
County:WELD #123Location:SESE 18 2N68W 6
Field:DJ HORIZONTAL CODELL - #16948Elevation:4942 ft.
Basin:DENVER (DJ) BASIN
Planned Location:208FSL  757 FELLat/Long: 40.132044 / -105.039375Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: SO - 10/1/2022             Measured TD: 1622 ft.    Vertical TD: 1620 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        SO - 10/1/2022
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:7/24/2020
Proposed Top PZ Location:Sec:18 Twp: 2N 68W Footage: 187 FSL  791 FEL
Bottom Hole Location:Sec:18 Twp: 2N 68W Footage: 187 FSL  791 FEL
Proposed Depth/Form:20232 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407-2458 , Unit Acreage: 1440, Drill Unit: 6:S2;7:All;18:N2,SE
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED
Cement:Sacks: 100, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 400, Top: 0 ft., Bottom: 1500 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 20232 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2729, Top: , Bottom: 20232 ft.
Wellbore Completed
Completion Date:6/2/2020
Spud Date:6/1/2020Spud Date Is:ACTUAL
Measured TD:1622 ft.Measured PB depth:1622 ft.
True Vertical TD:1620 ft.True Vertical PB depth:1620 ft.
Bottom Hole Location:Sec:18 Twp: 2N 68WFootage: 187 FSL  791 FEL
Log Types:
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: ACTUAL
Cement:Sacks: 100, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1622 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 575, Top: 0 ft., Bottom: 1622 ft., Determination Method: VISU
  No formation data to display.
Primary Well Designation:
Noticed Inactive      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveYNoticed Date
04/04/2025
Defined Inactive (SO )YDefined Inactive
10/01/2022
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
December 2024 - November 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
