Wellbore #00 Wellbore Classification: OW Status: PR - 3/30/2025 Measured TD: 17208 ft. Vertical TD: 6608 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/30/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 4/9/2026 | | Proposed Top PZ Location: | Sec:13 Twp: 5N 64W | Footage: 827 FNL 100 FEL | | Bottom Hole Location: | Sec:14 Twp: 5N 64W | Footage: 862 FNL 60 FWL | | Proposed Depth/Form: | 17313 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3425 , Unit Acreage: 720, Drill Unit: 5N-63W-18: W/2NW/4; | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 110 ft., Weight: 36.94 , Citings Type: PLANNED | | Cement: | Sacks: 60, Top: 0 ft., Bottom: 110 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1980 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 674, Top: 0 ft., Bottom: 1980 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17313 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2003, Top: , Bottom: 17313 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/9/2024 | | Spud Date: | 4/27/2024 | Spud Date Is: | ACTUAL | | Measured TD: | 17208 ft. | Measured PB depth: | 17188 ft. | | True Vertical TD: | 6608 ft. | True Vertical PB depth: | 6608 ft. | | Top PZ Location: | Sec:13 Twp: 5N 64W | Footage: 819 FNL 191 FEL | | Bottom Hole Location: | Sec:14 Twp: 5N 64W | Footage: 792 FNL 202 FWL | | Log Types: | CBL, MWD/LWD, (RES in 123-47463, RES in 123-47425) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 109 ft., Weight: 36.94 , Citings Type: ACTUAL | | Cement: | Sacks: 64, Top: 0 ft., Bottom: 109 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2065 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 877, Top: 0 ft., Bottom: 2065 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17195 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 1991, Top: 957 ft., Bottom: 17195 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3444 ft. | | | | | SUSSEX | 3955 ft. | | | | | SHANNON | 4728 ft. | | | | | TEEPEE BUTTES | 5710 ft. | | | | | SHARON SPRINGS | 6410 ft. | | | | | NIOBRARA | 6467 ft. | | | |
Formation NBRR Formation Classification: OW Status: SI - 12/1/2025 Interval Top: 7052 ft. Interval Bottom: 17160 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/26/2025 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 2/20/2025 | Treatment End Date: | 3/5/2025 | | Treatment Summary: | Niobrara completed with 396 bbls 28% HCL, 575,620 bbls slurry, 18,051,570 lb 40/140 Sand. | | Total fluid used in treatment (bbls): | 576016 | Max pressure during treatment (psi): | 8511 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 34 | | Total acid used in treatment (bbls): | 396 | Min frac gradient (psi/ft): | 0.98 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 575620 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 18051570 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6790 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/30/2025 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 528 | | BBLS_OIL | 598 | | BTU_GAS | 1278 | | CALC_BBLS_H2O | 528 | | CALC_BBLS_OIL | 598 | | CALC_GOR | 1269 | | CALC_MCF_GAS | 759 | | CASING_PRESS | 2259 | | GRAVITY_OIL | 42 | | MCF_GAS | 759 | | TUBING_PRESS | 1659 |
| | Perforation Data: | | Interval Top: | 7052 ft. | # Of Holes: | 1022 | | Interval Bottom: | 17160 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 76791 |
| Total Gas Produced (MCF) | 373219 |
| GOR | 4860 |
| GOR Determination | BOE |
| Average BOE per Day | 385.509 |
| Average MCFE per Day | 2235.935 |
| Federal Financial Assurance | i | |
|
|
