Wellbore #00 Wellbore Classification: OW Status: PR - 9/1/2025 Measured TD: 16955 ft. Vertical TD: 6509 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 9/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/22/2020 | | Proposed Top PZ Location: | Sec:7 Twp: 5N 63W | Footage: 635 FSL 422 FWL | | Bottom Hole Location: | Sec:8 Twp: 5N 63W | Footage: 709 FSL 247 FEL | | Proposed Depth/Form: | 17809 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 397, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 42 , Citings Type: PLANNED | | Cement: | Sacks: 6, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1850 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 658, Top: 0 ft., Bottom: 1850 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17809 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 1957, Top: , Bottom: 17809 ft. |
| | |
| Wellbore Completed | | Completion Date: | 8/17/2019 | | Spud Date: | 8/8/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 16955 ft. | Measured PB depth: | 16898 ft. | | True Vertical TD: | 6509 ft. | True Vertical PB depth: | 6509 ft. | | Top PZ Location: | Sec:7 Twp: 5N 63W | Footage: 635 FSL 422 FWL | | Bottom Hole Location: | Sec:8 Twp: 5N 63W | Footage: 709 FSL 247 FEL | | Log Types: | CBL, MWD/LWD, (RES in 123-19364) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 110 ft., Weight: 36.94 , Citings Type: ACTUAL | | Cement: | Sacks: 64, Top: 0 ft., Bottom: 110 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1928 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 655, Top: 0 ft., Bottom: 1928 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 16946 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 1700, Top: 3165 ft., Bottom: 16955 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PIERRE | 389 ft. | | | | | PARKMAN | 3464 ft. | | | | | SUSSEX | 4003 ft. | | | | | SHANNON | 4841 ft. | | | | | TEEPEE BUTTES | 5926 ft. | | | | | SHARON SPRINGS | 6638 ft. | | | | | NIOBRARA | 6702 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 9/1/2025 Interval Top: 7156 ft. Interval Bottom: 16808 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 12/23/2019 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 11/11/2019 | Treatment End Date: | 11/22/2019 | | Treatment Summary: | Niobrara completed with 152 bbls 28% HCl, 284,637 bbls slurry, 1,140,239 lbs 100 mesh, 9,768,984 lbs 40/70 | | Total fluid used in treatment (bbls): | 284789 | Max pressure during treatment (psi): | 8390 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 41 | | Total acid used in treatment (bbls): | 152 | Min frac gradient (psi/ft): | 0.96 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 284637 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 10909223 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6917 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 12/27/2019 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 327 | | BBLS_OIL | 705 | | BTU_GAS | 1300 | | CALC_BBLS_H2O | 327 | | CALC_BBLS_OIL | 705 | | CALC_GOR | 919 | | CALC_MCF_GAS | 648 | | CASING_PRESS | 1831 | | GRAVITY_OIL | 42 | | MCF_GAS | 648 | | TUBING_PRESS | 1332 |
| | Perforation Data: | | Interval Top: | 7156 ft. | # Of Holes: | 1276 | | Interval Bottom: | 16808 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 4350 |
| Total Gas Produced (MCF) | 102406 |
| GOR | 23541 |
| GOR Determination | MCFE |
| Average BOE per Day | 60.980 |
| Average MCFE per Day | 353.666 |
| Federal Financial Assurance | i | |
|
|
