Wellbore #00 Wellbore Classification: Status: PR - 6/1/2025 Measured TD: | Wellbore Data for Original Wellbore | Wellbore Classification: PR - 6/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 6/13/2025 | | Proposed Top PZ Location: | Sec:12 Twp: 7N 67W | Footage: 510 FNL 470 FEL | | Bottom Hole Location: | Sec:11 Twp: 7N 67W | Footage: 510 FNL 470 FWL | | Proposed Depth/Form: | 17528 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2267 , Unit Acreage: 1280, Drill Unit: SEC. 11 & 12: ALL | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 43 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 608, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17737 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2368, Top: 2500 ft., Bottom: 17737 ft. |
| | |
| Wellbore Completed | | Completion Date: | N/A | | Spud Date: | 12/13/2024 | Spud Date Is: | NOTICE | | Measured TD: | | Measured PB depth: | | | True Vertical TD: | | True Vertical PB depth: | | | No formation data to display. |
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 26569 |
| Total Gas Produced (MCF) | 17425 |
| GOR | 655 |
| GOR Determination | BOE |
| Average BOE per Day | 80.396 |
| Average MCFE per Day | 466.303 |
| Federal Financial Assurance | i | |
|
|
