Wellbore #00 Wellbore Classification: OW Status: PR - 2/1/2025 Measured TD: 17674 ft. Vertical TD: 6987 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 3/24/2030 | | Proposed Top PZ Location: | Sec:6 Twp: 6N 64W | Footage: 200 FSL 1672 FWL | | Bottom Hole Location: | Sec:31 Twp: 7N 64W | Footage: 200 FNL 1732 FWL | | Proposed Depth/Form: | 17682 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: , Unit Acreage: 640, Drill Unit: GWA | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-3384 , Unit Acreage: 1865, Drill Unit: Township 6 North, Ra | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 36.94 , Citings Type: PLANNED | | Cement: | Sacks: 175, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1950 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 640, Top: 0 ft., Bottom: 1950 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17718 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2059, Top: , Bottom: 17718 ft. |
| | |
| Wellbore Completed | | Completion Date: | 4/19/2024 | | Spud Date: | 3/21/2024 | Spud Date Is: | ACTUAL | | Measured TD: | 17674 ft. | Measured PB depth: | 17646 ft. | | True Vertical TD: | 6987 ft. | True Vertical PB depth: | 6987 ft. | | Top PZ Location: | Sec:6 Twp: 6N 64W | Footage: 238 FSL 1660 FWL | | Bottom Hole Location: | Sec:31 Twp: 7N 64W | Footage: 200 FNL 1735 FWL | | Log Types: | CBL, MWD/LWD, (IND-GR in 123-14166, IND-GR in 123-20207) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 109 ft., Weight: 45 , Citings Type: ACTUAL | | Cement: | Sacks: 64, Top: 0 ft., Bottom: 109 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2068 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 717, Top: 0 ft., Bottom: 2068 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17665 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 2066, Top: 935 ft., Bottom: 17665 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3703 ft. | | | | | SUSSEX | 4305 ft. | | | | | SHANNON | 5100 ft. | | | | | SHARON SPRINGS | 6864 ft. | | | | | NIOBRARA | 6900 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 3/2/2025 Interval Top: 7520 ft. Interval Bottom: 17631 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 2/23/2025 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/20/2024 | Treatment End Date: | 1/26/2025 | | Treatment Summary: | Niobrara completed with 890 bbls 28% HCL, 506,116 bbls slurry, 23,660,903 lb 40/140. | | Total fluid used in treatment (bbls): | 507006 | Max pressure during treatment (psi): | 8595 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 48 | | Total acid used in treatment (bbls): | 890 | Min frac gradient (psi/ft): | 0.98 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 0 | | Fresh water used in treatment (bbls): | 506116 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 23660903 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6609 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/2/2025 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1025 | | BBLS_OIL | 171 | | BTU_GAS | 1293 | | CALC_BBLS_H2O | 1025 | | CALC_BBLS_OIL | 171 | | CALC_GOR | 883 | | CALC_MCF_GAS | 151 | | CASING_PRESS | 1086 | | GRAVITY_OIL | 42 | | MCF_GAS | 151 | | TUBING_PRESS | 1637 |
| | Perforation Data: | | Interval Top: | 7520 ft. | # Of Holes: | 1019 | | Interval Bottom: | 17631 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 141368 |
| Total Gas Produced (MCF) | 423084 |
| GOR | 2992 |
| GOR Determination | BOE |
| Average BOE per Day | 583.564 |
| Average MCFE per Day | 3384.660 |
| Federal Financial Assurance | i | |
|
|
