Wellbore #00 Wellbore Classification: OW Status: PR - 5/1/2019 Measured TD: 15868 ft. Vertical TD: 7079 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 5/1/2019 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 1/30/2019 | | Proposed Top PZ Location: | Sec:29 Twp: 6N 66W | Footage: 959 FNL 2512 FWL | | Bottom Hole Location: | Sec:30 Twp: 6N 66W | Footage: 965 FNL 150 FWL | | Proposed Depth/Form: | 15561 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: CODL , Formation: CODELL , Order: 407-1934 , Unit Acreage: 1039, Drill Unit: Sec 29:W2,Sec 30:All | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 40 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 70, Top: 0 ft., Bottom: 40 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1750 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 531, Top: 0 ft., Bottom: 1750 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 15886 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 1980, Top: 0 ft., Bottom: 15886 ft. |
| | |
| Wellbore Completed | | Completion Date: | 4/21/2017 | | Spud Date: | 3/1/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 15868 ft. | Measured PB depth: | 15748 ft. | | True Vertical TD: | 7079 ft. | True Vertical PB depth: | 7080 ft. | | Top PZ Location: | Sec:29 Twp: 6N 66W | Footage: 949 FNL 2420 FWL | | Bottom Hole Location: | Sec:30 Twp: 6N 66W | Footage: 982 FNL 151 FWL | | Log Types: | MWD/LWD, CBL, Mud, (Resistivity on 123-44136). | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 40 ft., Weight: 55 , Citings Type: ACTUAL | | Cement: | Sacks: 35, Top: 0 ft., Bottom: 40 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1738 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 700, Top: 0 ft., Bottom: 1738 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 15832 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2104, Top: 0 ft., Bottom: 15741 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3556 ft. | | N | N | | SUSSEX | 4130 ft. | | N | N | | SHANNON | 4755 ft. | | N | N | | SHARON SPRINGS | 6842 ft. | | N | N | | NIOBRARA | 6888 ft. | | N | N | | FORT HAYS | 7339 ft. | | N | N | | CODELL | 7414 ft. | | N | N |
Formation FTHYS Formation Classification: OW Status: CM - 5/15/2018 Interval Top: 10140 ft. Interval Bottom: 10384 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 5/15/2018 | Treatment End Date: | N/A | | Treatment Summary: | Producing Interval: 10140'-10384'. | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 10140 ft. | # Of Holes: | 1440 | | Interval Bottom: | 10384 ft. | Hole Size: | 0.46 in. |
|
Formation NBRR Formation Classification: OW Status: CM - 5/15/2018 Interval Top: 9950 ft. Interval Bottom: 10140 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 5/15/2018 | Treatment End Date: | N/A | | Treatment Summary: | Producing Interval: 9950'-10140'. | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation NBRR. |
| | Perforation Data: | | Interval Top: | 9950 ft. | # Of Holes: | 1440 | | Interval Bottom: | 10140 ft. | Hole Size: | 0.46 in. |
|
Formation CODL Formation Classification: OW Status: CM - 5/15/2018 Interval Top: 7746 ft. Interval Bottom: 15677 ft.| Completed Information for Formation CODELL | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CODELL | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 5/15/2018 | Treatment End Date: | N/A | | Treatment Summary: | Producing Intervals: 7746'-9950'; 10384'-15677'. | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 7746 ft. | # Of Holes: | 1440 | | Interval Bottom: | 15677 ft. | Hole Size: | 0.46 in. |
|
Formation NBFHC Formation Classification: OW Status: PR - 5/1/2019 Interval Top: 7746 ft. Interval Bottom: 15677 ft.| Completed Information for Formation NIOBRARA-FT HAYS-CODELL | | 1st Production Date: | 8/30/2017 | Choke Size: | | | Formation Name: | NIOBRARA-FT HAYS-CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 7/1/2017 | Treatment End Date: | 7/8/2017 | | Treatment Summary: | Plug and perf completion type. 40 stages;
211190 total bbls fluid pumped: 211056 bbls slickwater and gel, 134 bbls 15% HCL acid used;
6477164 lbs. proppant (100+40/70+30/50 white sand) pumped. | | Total fluid used in treatment (bbls): | 211190 | Max pressure during treatment (psi): | 8245 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 40 | | Total acid used in treatment (bbls): | 134 | Min frac gradient (psi/ft): | 0.96 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 23592 | | Fresh water used in treatment (bbls): | 211056 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6477164 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7179 ft. | | Tubing Packer Depth: | 7156 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 10/14/2017 | Test Method: | flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 125 | | BBLS_OIL | 419 | | BTU_GAS | 1330 | | CALC_BBLS_H2O | 125 | | CALC_BBLS_OIL | 419 | | CALC_GOR | 1377 | | CALC_MCF_GAS | 577 | | GRAVITY_OIL | 48 | | MCF_GAS | 577 | | TUBING_PRESS | 1551 |
| | Perforation Data: | | Interval Top: | 7746 ft. | # Of Holes: | 1440 | | Interval Bottom: | 15677 ft. | Hole Size: | 0.46 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 3179 |
| Total Gas Produced (MCF) | 102939 |
| GOR | 32380 |
| GOR Determination | MCFE |
| Average BOE per Day | 57.137 |
| Average MCFE per Day | 331.412 |
| Federal Financial Assurance | i | |
|
|
