COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-43932		Well Classification: OW Status: PR - 11/23/2020
Well Name/No:Razor Fed #26I-3547
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:FUNDARE RESOURCES OPERATING COMPANY LLC - 10773
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date11/23/2020
FacilityID:448540LocationID:435160
County:WELD #123Location:NESE 26 10N58W 6
Field:WILDCAT - #99999Elevation:4711 ft.
Basin:DENVER (DJ) BASIN
Planned Location:2384FSL  793 FELLat/Long: 40.808911 / -103.825458Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.808906 / -103.825461Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 7/22/2017
End Date: 7/28/2017
Reported: 8/15/2017
Days to report: 18
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: AB - 6/7/2017             Measured TD: 5730 ft.    Vertical TD: 5606 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        AB - 6/7/2017
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:11/29/2018
Proposed Top PZ Location:Sec:26 Twp: 10N 58W Footage: 2553 FSL  596 FEL
Bottom Hole Location:Sec:35 Twp: 10N 58W Footage: 600 FSL  660 FEL
Proposed Depth/Form:13562 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 80 ft., Weight: 92 , Citings Type: PLANNED
Cement:Sacks: 179, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1950 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 617, Top: 0 ft., Bottom: 1950 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13562 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 2194, Top: 0 ft., Bottom: 13562 ft.
Wellbore Completed
Completion Date:6/8/2017
Spud Date:6/7/2017Spud Date Is:ACTUAL
Measured TD:5730 ft.Measured PB depth:2595 ft.
True Vertical TD:5606 ft.True Vertical PB depth:2559 ft.
Bottom Hole Location:Sec:26 Twp: 10N 58WFootage: 2300 FNL  679 FEL
Log Types:Mud Log, MWD/LWD (Triple Combo in API 123-38488)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 101 ft., Weight: 75 , Citings Type: ACTUAL
Cement:Sacks: 153, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2085 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 560, Top: 0 ft., Bottom: 2085 ft., Determination Method: VISU
Casing:String Type: OPEN HOLE, Hole Size: 8.5 in., Size: , Top: 2085 ft., Depth: 5730 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: , Bottom: , Determination Method:
Additional Cement:String Type: OPEN HOLE , Top: 5330 ft., Depth: , Bottom: 5730 ft., Sacks: 155, Method:
Additional Cement:String Type: OPEN HOLE , Top: 4930 ft., Depth: , Bottom: 5330 ft., Sacks: 155, Method:
Additional Cement:String Type: OPEN HOLE , Top: 5386 ft., Depth: , Bottom: 5457 ft., Sacks: 80, Method: SQUEEZE
Additional Cement:String Type: OPEN HOLE , Top: 5457 ft., Depth: , Bottom: 5620 ft., Sacks: 80, Method: SQUEEZE
Additional Cement:String Type: OPEN HOLE , Top: 2379 ft., Depth: , Bottom: 2779 ft., Sacks: 175, Method:
Additional Cement:String Type: OPEN HOLE , Top: 5226 ft., Depth: , Bottom: 5678 ft., Sacks: 155, Method: SQUEEZE
  No formation data to display.

Sidetrack #01             Wellbore Classification: OW             Status: PR - 11/23/2020             Measured TD: 13078 ft.    Vertical TD: 5818 ft.

 Wellbore Data for Sidetrack #01Wellbore Classification: OW        PR - 11/23/2020
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:6/14/2019
Proposed Top PZ Location:Sec:26 Twp: 10N 58W Footage: 2182 FSL  642 FEL
Bottom Hole Location:Sec:35 Twp: 10N 58W Footage: 600 FSL  660 FEL
Proposed Depth/Form:13161 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 535-508 , Unit Acreage: 960, Drill Unit: S/2 26; All 35
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 80 ft., Weight: 92 , Citings Type: PLANNED
Cement:Sacks: 179, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2085 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 659, Top: 0 ft., Bottom: 2085 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13161 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 2194, Top: 0 ft., Bottom: 13161 ft.
Wellbore Completed
Completion Date:6/19/2017
Spud Date:6/7/2017Spud Date Is:ACTUAL
Measured TD:13078 ft.Measured PB depth:13024 ft.
True Vertical TD:5818 ft.True Vertical PB depth:5816 ft.
Top PZ Location:Sec:26 Twp: 10N 58WFootage: 2083 FSL  661 FEL
Bottom Hole Location:Sec:35 Twp: 10N 58WFootage: 601 FSL  643 FEL
Log Types:Mud Log, MWD/LWD, CBL (Triple Combo in API 123-38488)
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 101 ft., Weight: 75 , Citings Type: ACTUAL
Cement:Sacks: 153, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2085 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 560, Top: 0 ft., Bottom: 2085 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13074 ft., Weight: 20 , Citings Type: ACTUAL
Cement:Sacks: 2245, Top: 3030 ft., Bottom: 13078 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PIERRE1411 ft.NN
HYGIENE3176 ft.NN
SHARON SPRINGS5522 ft.NN
NIOBRARA5525 ft.NN
FORT HAYS5811 ft.NN
CODELL5846 ft.NN
CARLILE5857 ft.NN

Formation FTHYS                   Formation Classification:  OW                   Status:  PR - 11/23/2020                Interval Top: 10893 ft.    Interval Bottom: 11423 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:10/4/2017Choke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:11/23/2020Treatment End Date:N/A
Treatment Summary:Completed Depths: 10893'-11098' (30 shots); 11346'-11423' (20 shots)
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:10893 ft.# Of Holes:50
Interval Bottom:11423 ft.Hole Size:

Formation CARL                     Formation Classification:  OW                     Status:  PR - 11/23/2020                Interval Top: 6343 ft.    Interval Bottom: 9557 ft.

 Completed Information for Formation CARLILE
1st Production Date:10/4/2017Choke Size:
Formation Name:CARLILECommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:11/23/2020Treatment End Date:N/A
Treatment Summary:Completed Depths: 6343'-6345' (10 shots); 8314'-9557' (180 shots)
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CARL.
Perforation Data:
Interval Top:6343 ft.# Of Holes:190
Interval Bottom:9557 ft.Hole Size:

Formation CLCDFH                 Formation Classification:  OW                 Status:  CM - 11/16/2017                Interval Top: 6270 ft.    Interval Bottom: 12968 ft.

 Completed Information for Formation CARLILE-CODELL-FORT HAYS
1st Production Date:10/4/2017Choke Size:
Formation Name:CARLILE-CODELL-FORT HAYSCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:FRACTURE STIMULATION
Treatment Date:7/22/2017Treatment End Date:7/28/2017
Treatment Summary:30 Stage Plug & Perf, 1005000 lbs 100 Mesh, 4155060 lbs 30/50 Prem White sand, 12 bbls 15% HCl, 192586 bbls slickwater
Total fluid used in treatment (bbls):192598Max pressure during treatment (psi):7112
Total gas used in treatment (mcf):0Fluid density (lbs/gal):8.33
Type Of gas:Number Of staged intervals:30
Total acid used in treatment (bbls):12Min frac gradient (psi/ft):0.79
Recycled water used in treatment (bbls):0Total flowback volume recovered (bbls):3879
Fresh water used in treatment (bbls):192586Disposition method For flowback:DISPOSAL
Total proppant used (lbs):5160060Green completions techniques utilized:Yes
Reason green techniques Not utilized:
Tubing Size:3 in.Tubing Setting Depth:5900 ft.
Tubing Packer Depth:5883 ft.Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:11/16/2017Test Method:Separator
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 243
BBLS_OIL 58
BTU_GAS 1321
CALC_BBLS_H2O 243
CALC_BBLS_OIL 58
CALC_GOR 345
CALC_MCF_GAS 20
CASING_PRESS 850
GRAVITY_OIL 40
MCF_GAS 20
TUBING_PRESS 360
Perforation Data:
Interval Top:6270 ft.# Of Holes:910
Interval Bottom:12968 ft.Hole Size:0.375 in.

Formation CODL                     Formation Classification:  OW                     Status:  PR - 11/23/2020                Interval Top: 6270 ft.    Interval Bottom: 12968 ft.

 Completed Information for Formation CODELL
1st Production Date:10/4/2017Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:11/23/2020Treatment End Date:N/A
Treatment Summary:Completed Depths: 6270'-6272' (10 shots); 6416'-8243' (260 shots); 9628'-10798' (170 shots); 11196'-11273' (20 shots); 11496'-12968' (210 shots)
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:6270 ft.# Of Holes:670
Interval Bottom:12968 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)2285
Total Gas Produced (MCF)7789
GOR3408
GOR DeterminationBOE
Average BOE per Day9.993
Average MCFE per Day57.961

 Federal Financial Assurance  i

 Tribal Well  i No
