Wellbore #00 Wellbore Classification: OW Status: PR - 12/2/2018 Measured TD: 11995 ft. Vertical TD: 7340 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 12/2/2018 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/11/2018 | | Proposed Top PZ Location: | Sec:14 Twp: 1N 67W | Footage: 888 FSL 1011 FEL | | Bottom Hole Location: | Sec:14 Twp: 1N 67W | Footage: 49 FNL 912 FEL | | Proposed Depth/Form: | 12150 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 400, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 40 ft., Weight: 42.1 , Citings Type: PLANNED | | Cement: | Sacks: 30, Top: 0 ft., Bottom: 40 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1800 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 700, Top: 0 ft., Bottom: 1800 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 12140 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 1419, Top: , Bottom: 12140 ft. |
| | |
| Wellbore Completed | | Completion Date: | 9/6/2017 | | Spud Date: | 8/9/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 11995 ft. | Measured PB depth: | 11942 ft. | | True Vertical TD: | 7340 ft. | True Vertical PB depth: | 7339 ft. | | Top PZ Location: | Sec:14 Twp: 1N 67W | Footage: 1122 FSL 1086 FEL | | Bottom Hole Location: | Sec:14 Twp: 1N 67W | Footage: 56 FNL 928 FEL | | Log Types: | MWD/GR, CALI, CBL, CNL RUN ON NORDEN 1C-14HZ (API: 05-123-43576). | | Log Types: | | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 97 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 64, Top: 0 ft., Bottom: 97 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1868 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 667, Top: 0 ft., Bottom: 1868 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 7 in., Top: 0 ft., Depth: 6346 ft., Weight: 26 , Citings Type: ACTUAL | | Cement: | Sacks: 530, Top: 30 ft., Bottom: 6346 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6107 ft., Depth: 11965 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 360, Top: 6107 ft., Bottom: 11965 ft., Determination Method: CALC | | Casing: | String Type: 2ND LINER, Hole Size: , Size: 4.5 in., Top: 0 ft., Depth: 6107 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 305, Top: 2651 ft., Bottom: 6107 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4611 ft. | | | | | SHARON SPRINGS | 7319 ft. | | | | | NIOBRARA | 7354 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 12/2/2018 Interval Top: 7754 ft. Interval Bottom: 11867 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 11/2/2018 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 12/2/2018 | Treatment End Date: | N/A | | Treatment Summary: | PERF AND FRAC FROM 7754-11867.
229 BBL 7.5% HCL ACID, 2,267 BBL PUMP DOWN, 145,599 BBL SLICKWATER, 148,094 TOTAL FLUID, 3,332,780# 40/70 OTTAWA/ST. PETERS, 3,332,780# TOTAL SAND. | | Total fluid used in treatment (bbls): | 148094 | Max pressure during treatment (psi): | 7484 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 21 | | Total acid used in treatment (bbls): | 229 | Min frac gradient (psi/ft): | 0.87 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 5825 | | Fresh water used in treatment (bbls): | 147865 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 3332780 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7429 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 12/2/2018 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 290 | | BBLS_OIL | 222 | | BTU_GAS | 1707 | | CALC_BBLS_H2O | 290 | | CALC_BBLS_OIL | 222 | | CALC_GOR | 1081 | | CALC_MCF_GAS | 240 | | CASING_PRESS | 2000 | | GRAVITY_OIL | 55 | | MCF_GAS | 240 | | TUBING_PRESS | 1200 |
| | Perforation Data: | | Interval Top: | 7754 ft. | # Of Holes: | 664 | | Interval Bottom: | 11867 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1490 |
| Total Gas Produced (MCF) | 35016 |
| GOR | 23500 |
| GOR Determination | MCFE |
| Average BOE per Day | 20.635 |
| Average MCFE per Day | 119.689 |
| Federal Financial Assurance | i | |
|
|
