COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-43324		Well Classification: LO Status: AP - 5/29/2024
Well Name/No:Horsetail #29G-3209
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:FUNDARE RESOURCES OPERATING COMPANY LLC - 10773
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:APStatus Date5/29/2024
FacilityID:446426LocationID:435861
County:WELD #123Location:SWNE 29 10N57W 6
Field:WILDCAT - #99999Elevation:4695 ft.
Basin:DENVER (DJ) BASIN
Planned Location:2329FNL  2119 FELLat/Long: 40.810700 / -103.773011Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: AP - 5/29/2024             Measured TD:

 Wellbore Data for Original WellboreWellbore Classification:         AP - 5/29/2024
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:5/28/2027
Proposed Top PZ Location:Sec:29 Twp: 10N 57W Footage: 2561 FNL  150 FWL
Bottom Hole Location:Sec:20 Twp: 10N 57W Footage: 100 FNL  150 FWL
Proposed Depth/Form:14913 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 535-1412 , Unit Acreage: 960, Drill Unit: T10N-R57W, N/2 S29,
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 80 ft., Weight: 92 , Citings Type: PLANNED
Cement:Sacks: 179, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2000 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 885, Top: 0 ft., Bottom: 2000 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 14913 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 2269, Top: , Bottom: 14913 ft.
Wellbore Completed
Completion Date:N/A
Measured TD:Measured PB depth:
True Vertical TD:True Vertical PB depth:
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
