Wellbore #00 Wellbore Classification: OW Status: PR - 3/1/2025 Measured TD: 12310 ft. Vertical TD: 7099 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 6/21/2018 | | Proposed Top PZ Location: | Sec:22 Twp: 3N 68W | Footage: 1052 FSL 150 FEL | | Bottom Hole Location: | Sec:22 Twp: 3N 68W | Footage: 1127 FSL 461 FWL | | Proposed Depth/Form: | 12342 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 400, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1800 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 710, Top: 0 ft., Bottom: 1800 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 12332 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 1442, Top: , Bottom: 12332 ft. |
| | |
| Wellbore Completed | | Completion Date: | 7/14/2017 | | Spud Date: | 5/25/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 12310 ft. | Measured PB depth: | 12203 ft. | | True Vertical TD: | 7099 ft. | True Vertical PB depth: | 7103 ft. | | Top PZ Location: | Sec:22 Twp: 3N 68W | Footage: 1065 FSL 158 FEL | | Bottom Hole Location: | Sec:22 Twp: 3N 68W | Footage: 1101 FSL 455 FWL | | Log Types: | CBL, MWD/GR, (RESISTIVITY in 05-123-21269, CNL in 05-123-43307) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 97 ft., Weight: 42 , Citings Type: ACTUAL | | Cement: | Sacks: 64, Top: 0 ft., Bottom: 97 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1885 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 733, Top: 0 ft., Bottom: 1885 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 12296 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 1170, Top: 936 ft., Bottom: 12296 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4300 ft. | | | | | SHARON SPRINGS | 7240 ft. | | | | | NIOBRARA | 7364 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 3/1/2025 Interval Top: 7654 ft. Interval Bottom: 12194 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 10/18/2017 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 9/16/2017 | Treatment End Date: | 9/26/2017 | | Treatment Summary: | PERF AND FRAC FROM 7654-12,194.
543 BBL 7.5% HCL ACID, 6,351 BBL BIO WATER, 158,737 BBL SLICKWATER, - 165,630 TOTAL FLUID
1,368,450# 40/70 OTTAWA/ST. PETERS, - 1,368,450# TOTAL SAND.
| | Total fluid used in treatment (bbls): | 165630 | Max pressure during treatment (psi): | 7475 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 45 | | Total acid used in treatment (bbls): | 543 | Min frac gradient (psi/ft): | 0.84 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 7865 | | Fresh water used in treatment (bbls): | 165088 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 1368450 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 10/24/2017 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 92 | | BBLS_OIL | 55 | | BTU_GAS | 1310 | | CALC_BBLS_H2O | 92 | | CALC_BBLS_OIL | 55 | | CALC_GOR | 1309 | | CALC_MCF_GAS | 72 | | CASING_PRESS | 1250 | | GRAVITY_OIL | 51 | | MCF_GAS | 72 |
| | Perforation Data: | | Interval Top: | 7654 ft. | # Of Holes: | 1104 | | Interval Bottom: | 12194 ft. | Hole Size: | 0.44 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1664 |
| Total Gas Produced (MCF) | 26883 |
| GOR | 16155 |
| GOR Determination | MCFE |
| Average BOE per Day | 17.167 |
| Average MCFE per Day | 99.551 |
| Federal Financial Assurance | i | |
|
|
