Wellbore #00 Wellbore Classification: OW Status: PR - 4/11/2020 Measured TD: 13632 ft. Vertical TD: 5574 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/11/2020 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 4/21/2018 | | Proposed Top PZ Location: | Sec:30 Twp: 10N 57W | Footage: 2062 FSL 129 FEL | | Bottom Hole Location: | Sec:31 Twp: 10N 57W | Footage: 101 FSL 187 FEL | | Proposed Depth/Form: | 13700 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-508 , Unit Acreage: 960, Drill Unit: S/2 30, All 31 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 179, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1550 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 695, Top: 0 ft., Bottom: 1550 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 13700 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2001, Top: 0 ft., Bottom: 13700 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/2/2017 | | Spud Date: | 4/26/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 13632 ft. | Measured PB depth: | 13583 ft. | | True Vertical TD: | 5574 ft. | True Vertical PB depth: | 5575 ft. | | Top PZ Location: | Sec:30 Twp: 10N 57W | Footage: 2062 FSL 129 FEL | | Bottom Hole Location: | Sec:31 Twp: 10N 57W | Footage: 101 FSL 187 FEL | | Log Types: | CBL, MWD/LWD, MUD LOG (CAL, NEU, IND, GR, COMP in API 05-123-43123) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 101 ft., Weight: 75 , Citings Type: ACTUAL | | Cement: | Sacks: 153, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2071 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 615, Top: 0 ft., Bottom: 2071 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13624 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2360, Top: 340 ft., Bottom: 13632 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PIERRE | 1410 ft. | | N | N | | HYGIENE | 3143 ft. | | N | N | | SUSSEX | 3746 ft. | | N | N | | SHARON SPRINGS | 5447 ft. | | N | N | | NIOBRARA | 5456 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 4/11/2020 Interval Top: 6351 ft. Interval Bottom: 13522 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/27/2020 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 3/2/2020 | Treatment End Date: | 3/8/2020 | | Treatment Summary: | 36 Stage Plug & Perf, 1392435# 100 Mesh, 9835093# 40/70 sand, 1169 bbls 15% HCL, 370459 bbls Slickwater | | Total fluid used in treatment (bbls): | 371628 | Max pressure during treatment (psi): | 8796 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 36 | | Total acid used in treatment (bbls): | 1169 | Min frac gradient (psi/ft): | 0.80 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 10483 | | Fresh water used in treatment (bbls): | 370459 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 11227527 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 5555 ft. | | Tubing Packer Depth: | 5548 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/11/2020 | Test Method: | Separator | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 832 | | BBLS_OIL | 86 | | BTU_GAS | 1370 | | CALC_BBLS_H2O | 832 | | CALC_BBLS_OIL | 86 | | CALC_GOR | 640 | | CALC_MCF_GAS | 55 | | CASING_PRESS | 886 | | GRAVITY_OIL | 35 | | MCF_GAS | 55 | | TUBING_PRESS | 348 |
| | Perforation Data: | | Interval Top: | 6351 ft. | # Of Holes: | 1372 | | Interval Bottom: | 13522 ft. | Hole Size: | 0.375 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 9663 |
| Total Gas Produced (MCF) | 19165 |
| GOR | 1983 |
| GOR Determination | BOE |
| Average BOE per Day | 35.506 |
| Average MCFE per Day | 205.972 |
| Federal Financial Assurance | i | |
|
|
