Wellbore #00 Wellbore Classification: OW Status: PR - 3/10/2017 Measured TD: 12092 ft. Vertical TD: 6713 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/10/2017 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 4/19/2018 | | Proposed Top PZ Location: | Sec:18 Twp: 5N 64W | Footage: 1385 FNL 35 FEL | | Bottom Hole Location: | Sec:18 Twp: 5N 64W | Footage: 1305 FNL 106 FEL | | Proposed Depth/Form: | 12253 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 480, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1450 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 920, Top: 0 ft., Bottom: 1450 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 12253 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2035, Top: 0 ft., Bottom: 12253 ft. |
| | |
| Wellbore Completed | | Completion Date: | 7/17/2016 | | Spud Date: | 7/12/2016 | Spud Date Is: | ACTUAL | | Measured TD: | 12092 ft. | Measured PB depth: | 12046 ft. | | True Vertical TD: | 6713 ft. | True Vertical PB depth: | 6715 ft. | | Top PZ Location: | Sec:18 Twp: 5N 64W | Footage: 1385 FNL 35 FEL | | Bottom Hole Location: | Sec:18 Twp: 5N 64W | Footage: 1305 FNL 106 FEL | | Log Types: | CBL, MWD (DIL in 123-43088-00) | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1517 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 720, Top: 0 ft., Bottom: 1517 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 12061 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 1980, Top: 0 ft., Bottom: 12061 ft., Determination Method: VISU | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3527 ft. | | | | | SUSSEX | 4247 ft. | | | | | SHANNON | 4997 ft. | | | | | SHARON SPRINGS | 6494 ft. | | | | | NIOBRARA | 6653 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 3/10/2017 Interval Top: 7127 ft. Interval Bottom: 12001 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/2/2017 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 1/3/2017 | Treatment End Date: | 1/16/2017 | | Treatment Summary: | 30 Stage Plug and Perf, Perf'd from 7127-11810, 3 Toe sleeves from 11105-12001
Total Fluid: 99,852 bbls
Gel Fluid: 55,855 bbls
Slickwater Fluid: 42,971 bbls
15% HCl Acid: 1,026
Total Proppant: 4,691,300 lbs
Silica Proppant: 4,691,300 lbs
Method for determining flowback: measuring flowback tank volumes | | Total fluid used in treatment (bbls): | 99852 | Max pressure during treatment (psi): | 4310 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 30 | | Total acid used in treatment (bbls): | 1026 | Min frac gradient (psi/ft): | 1.00 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 4059 | | Fresh water used in treatment (bbls): | 98826 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 4691300 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6769 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/10/2017 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 209 | | BBLS_OIL | 427 | | BTU_GAS | 1322 | | CALC_BBLS_H2O | 209 | | CALC_BBLS_OIL | 427 | | CALC_GOR | 2854 | | CALC_MCF_GAS | 1219 | | CASING_PRESS | 2649 | | GRAVITY_OIL | 50 | | MCF_GAS | 1219 | | TUBING_PRESS | 2024 |
| | Perforation Data: | | Interval Top: | 7127 ft. | # Of Holes: | 1044 | | Interval Bottom: | 12001 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1242 |
| Total Gas Produced (MCF) | 41790 |
| GOR | 33647 |
| GOR Determination | MCFE |
| Average BOE per Day | 23.130 |
| Average MCFE per Day | 134.191 |
| Federal Financial Assurance | i | |
|
|
