Wellbore #00 Wellbore Classification: OW Status: PR - 8/1/2017 Measured TD: 13948 ft. Vertical TD: 5830 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 8/1/2017 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 6/13/2017 | | Proposed Top PZ Location: | Sec:7 Twp: 10N 57W | Footage: 2549 FSL 1206 FWL | | Bottom Hole Location: | Sec:18 Twp: 10N 57W | Footage: 100 FSL 1135 FWL | | Proposed Depth/Form: | 13914 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-508 , Unit Acreage: 960, Drill Unit: S/2 S7, All S18 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 179, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1830 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 711, Top: 0 ft., Bottom: 1830 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 13914 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2028, Top: 0 ft., Bottom: 13914 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6 in., Size: 4.5 in., Top: 5333 ft., Depth: 13830 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 2/21/2016 | | Spud Date: | 2/16/2016 | Spud Date Is: | ACTUAL | | Measured TD: | 13948 ft. | Measured PB depth: | 13879 ft. | | True Vertical TD: | 5830 ft. | True Vertical PB depth: | 5829 ft. | | Top PZ Location: | Sec:7 Twp: 10N 57W | Footage: 2505 FSL 1194 FWL | | Bottom Hole Location: | Sec:18 Twp: 10N 57W | Footage: 34 FSL 1134 FWL | | Log Types: | LWD/MWD, Mud, CBL, (NEU in API 123-41643) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 101 ft., Weight: 65 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2038 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 794, Top: 0 ft., Bottom: 2038 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13928 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 2275, Top: 1110 ft., Bottom: 13928 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PIERRE | 1750 ft. | | N | N | | HYGIENE | 3601 ft. | | N | N | | SHARON SPRINGS | 5704 ft. | | N | N | | NIOBRARA | 5712 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 8/13/2017 Interval Top: 6162 ft. Interval Bottom: 13834 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 8/7/2017 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 4/10/2017 | Treatment End Date: | 4/15/2017 | | Treatment Summary: | 30 Stage Plug & Perf, 940158lbs # 100 Mesh , 3852270lbs # 40/70 Prem White sand, 310 bbls 15% HCl, 182881 bbls slickwater | | Total fluid used in treatment (bbls): | 183191 | Max pressure during treatment (psi): | 7498 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 30 | | Total acid used in treatment (bbls): | 310 | Min frac gradient (psi/ft): | 0.80 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 7247 | | Fresh water used in treatment (bbls): | 182881 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 4792428 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 3 in. | Tubing Setting Depth: | 5175 ft. | | Tubing Packer Depth: | 5165 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/13/2017 | Test Method: | Separator | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 626 | | BBLS_OIL | 331 | | BTU_GAS | 1381 | | CALC_BBLS_H2O | 626 | | CALC_BBLS_OIL | 331 | | CALC_GOR | 631 | | CALC_MCF_GAS | 209 | | CASING_PRESS | 150 | | GRAVITY_OIL | 36 | | MCF_GAS | 209 | | TUBING_PRESS | 525 |
| | Perforation Data: | | Interval Top: | 6162 ft. | # Of Holes: | 1201 | | Interval Bottom: | 13834 ft. | Hole Size: | 0.375 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 832 |
| Total Gas Produced (MCF) | 3413 |
| GOR | 4102 |
| GOR Determination | BOE |
| Average BOE per Day | 3.872 |
| Average MCFE per Day | 22.447 |
| Federal Financial Assurance | i | |
|
|
