COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-40334		Well Classification: OW Status: PR - 3/10/2022
Well Name/No:JOHNSON #01N-65W-30-7H
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:VERDAD RESOURCES LLC - 10651
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date3/10/2022
FacilityID:439159LocationID:439158
County:WELD #123Location:SESW 30 1N65W 6
Field:WATTENBERG - #90750Elevation:5000 ft.
Basin:DENVER (DJ) BASIN
Planned Location:230FSL  1774 FWLLat/Long: 40.015685 / -104.709814Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.015685 / -104.709814Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 12/18/2021
End Date: 12/30/2021
Reported: 1/24/2022
Days to report: 25
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 3/10/2022             Measured TD: 17995 ft.    Vertical TD: 7423 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 3/10/2022
Wellbore PermitHORIZONTAL
Permit #:Expiration Date:7/9/2021
Proposed Top PZ Location:Sec:30 Twp: 1N 65W Footage: 460 FSL  1864 FWL
Bottom Hole Location:Sec:19 Twp: 1N 65W Footage: 460 FSL  1864 FWL
Proposed Depth/Form:17508 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407-2599 , Unit Acreage: 640, Drill Unit: Sec30 W2,Sec19 W2
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 407-2599 , Unit Acreage: 640, Drill Unit: S 30: W/2, 19: W/2
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED
Cement:Sacks: 70, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2291 ft., Weight: 40 , Citings Type: PLANNED
Cement:Sacks: 970, Top: 0 ft., Bottom: 2291 ft.
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17948 ft., Weight: 20 , Citings Type: PLANNED
Cement:Sacks: 2242, Top: 0 ft., Bottom: 17948 ft.
Casing:String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7410 ft., Depth: 11868 ft., Weight: 13.5# , Citings Type: PLANNED
Cement:Sacks: , Top: , Bottom:
Wellbore Completed
Completion Date:11/6/2021
Spud Date:5/17/2021Spud Date Is:ACTUAL
Measured TD:17995 ft.Measured PB depth:17913 ft.
True Vertical TD:7423 ft.True Vertical PB depth:7423 ft.
Top PZ Location:Sec:30 Twp: 1N 65WFootage: 329 FSL  1871 FWL
Bottom Hole Location:Sec:19 Twp: 1N 65WFootage: 201 FNL  1857 FWL
Log Types:
Log Types:MWD/LWD,CBL, RES run on Johnson 01N-65W-30-4H (API 05-123-40337)
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: ACTUAL
Cement:Sacks: 70, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2291 ft., Weight: 40 , Citings Type: ACTUAL
Cement:Sacks: 970, Top: 0 ft., Bottom: 2291 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 390 ft., Depth: 17979 ft., Weight: 20 , Citings Type: ACTUAL
Cement:Sacks: 2475, Top: 276 ft., Bottom: 17979 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
FOX HILLS785 ft.
PARKMAN4308 ft.
SUSSEX4653 ft.
SHANNON5147 ft.
SHARON SPRINGS7122 ft.
NIOBRARA7136 ft.
FORT HAYS7770 ft.
CODELL7929 ft.

Formation CD-FH                   Formation Classification:  OW                   Status:  PR - 3/10/2022                 Interval Top: 7910 ft.    Interval Bottom: 17818 ft.

 Completed Information for Formation CODELL-FORT HAYS
1st Production Date:3/7/2022Choke Size:
Formation Name:CODELL-FORT HAYSCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:HYDRAULIC FRACTURING
Treatment Date:12/18/2021Treatment End Date:12/30/2021
Treatment Summary:FR Water 505773 bbl, Treated Water 12927 bbl, Fresh Water 2498 bbl, 28% HCL 834 bbls (Fresh Water Total 21893870 Gals), Brine Water 85 bbls. Proppant: 100 Mesh 3673769 lbs,200 Mesh 51200 lbs, 40/70 White 16707020 lbs. Flowback is measured by strapping a flowback tank every hour during initial flowback and from tank gauges during permanent facility flowback.
Total fluid used in treatment (bbls):522117Max pressure during treatment (psi):11570
Total gas used in treatment (mcf):Fluid density (lbs/gal):8.34
Type Of gas:Number Of staged intervals:48
Total acid used in treatment (bbls):834Min frac gradient (psi/ft):0.91
Recycled water used in treatment (bbls):85Total flowback volume recovered (bbls):958
Fresh water used in treatment (bbls):521198Disposition method For flowback:DISPOSAL
Total proppant used (lbs):20431989Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:2.375 in.Tubing Setting Depth:7460 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:3/10/2022Test Method:Flowing
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 203
BBLS_OIL 550
BTU_GAS 1311
CALC_BBLS_H2O 203
CALC_BBLS_OIL 550
CALC_GOR 909
CALC_MCF_GAS 500
CASING_PRESS 2413
GRAVITY_OIL 42
MCF_GAS 500
TUBING_PRESS 1985
Perforation Data:
Interval Top:7910 ft.# Of Holes:1584
Interval Bottom:17818 ft.Hole Size:0.36 in.

Formation CODL                     Formation Classification:  OW                     Status:  CM - 12/18/2025                Interval Top: 7910 ft.    Interval Bottom: 17818 ft.

 Completed Information for Formation CODELL
1st Production Date:N/AChoke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:12/18/2025Treatment End Date:N/A
Treatment Summary:Perf Intervals: 7929-12703, 12758-13107, 13529-13973, 14068-17818
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:7910 ft.# Of Holes:1284
Interval Bottom:17818 ft.Hole Size:0.36 in.

Formation FTHYS                   Formation Classification:  OW                   Status:  CM - 12/18/2025                Interval Top: 7910 ft.    Interval Bottom: 17818 ft.

 Completed Information for Formation FORT HAYS
1st Production Date:N/AChoke Size:
Formation Name:FORT HAYSCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:12/18/2025Treatment End Date:N/A
Treatment Summary:Perf Intervals: 7910-7928, 12704-12757, 13108-13528, 13974-14067
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation FTHYS.
Perforation Data:
Interval Top:7910 ft.# Of Holes:1284
Interval Bottom:17818 ft.Hole Size:0.36 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)40295
Total Gas Produced (MCF)329660
GOR8181
GOR DeterminationBOE
Average BOE per Day265.954
Average MCFE per Day1542.550

 Federal Financial Assurance  i

 Tribal Well  i No
