Wellbore #00 Wellbore Classification: OW Status: PR - 3/8/2022 Measured TD: 17837 ft. Vertical TD: 7175 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/8/2022 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/9/2021 | | Proposed Top PZ Location: | Sec:30 Twp: 1N 65W | Footage: 330 FSL 613 FWL | | Bottom Hole Location: | Sec:19 Twp: 1N 65W | Footage: 379 FNL 674 FWL | | Proposed Depth/Form: | 17285 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 407-2599 , Unit Acreage: 640, Drill Unit: S 30: W/2, 19: W/2 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 70, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2314 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 990, Top: 0 ft., Bottom: 2314 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17707 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 2215, Top: 0 ft., Bottom: 17707 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7450 ft., Depth: 11905 ft., Weight: 13.5# , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 11/11/2021 | | Spud Date: | 5/16/2021 | Spud Date Is: | ACTUAL | | Measured TD: | 17837 ft. | Measured PB depth: | 17755 ft. | | True Vertical TD: | 7175 ft. | True Vertical PB depth: | 7176 ft. | | Top PZ Location: | Sec:30 Twp: 1N 65W | Footage: 330 FSL 613 FWL | | Bottom Hole Location: | Sec:19 Twp: 1N 65W | Footage: 379 FNL 674 FWL | | Log Types: | | | Log Types: | MWD/LWD,CBL, RES run on Johnson 01N-65W-30-4H (API 05-123-40337) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: ACTUAL | | Cement: | Sacks: 70, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2314 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 990, Top: 0 ft., Bottom: 2314 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 17837 ft., Weight: 23 , Citings Type: ACTUAL | | Cement: | Sacks: 2444, Top: 84 ft., Bottom: 17837 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | FOX HILLS | 787 ft. | | | | | PARKMAN | 4304 ft. | | | | | SUSSEX | 4711 ft. | | | | | SHANNON | 5314 ft. | | | | | SHARON SPRINGS | 7369 ft. | | | | | NIOBRARA | 7384 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 3/8/2022 Interval Top: 7780 ft. Interval Bottom: 17662 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 3/7/2022 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 12/31/2021 | Treatment End Date: | 1/9/2022 | | Treatment Summary: | FR Water 505081 bbl, Treated Water 11278 bbl, Fresh Water 2600 bbl, 28% HCL 834 bbls (Fresh Water Total 21802083 Gals), Brine Water 138 bbls. Proppant: 100 Mesh 3723860 lbs, 40/70 White 16813762 lbs. Flowback is measured by strapping a flowback tank every hour during initial flowback and from tank gauges during permanent facility flowback. | | Total fluid used in treatment (bbls): | 519932 | Max pressure during treatment (psi): | 11396 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 48 | | Total acid used in treatment (bbls): | 834 | Min frac gradient (psi/ft): | 0.96 | | Recycled water used in treatment (bbls): | 138 | Total flowback volume recovered (bbls): | 8008 | | Fresh water used in treatment (bbls): | 518960 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 20537622 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7270 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/8/2022 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 296 | | BBLS_OIL | 388 | | BTU_GAS | 1311 | | CALC_BBLS_H2O | 296 | | CALC_BBLS_OIL | 388 | | CALC_GOR | 732 | | CALC_MCF_GAS | 284 | | CASING_PRESS | 1637 | | GRAVITY_OIL | 42 | | MCF_GAS | 284 | | TUBING_PRESS | 2317 |
| | Perforation Data: | | Interval Top: | 7780 ft. | # Of Holes: | 1584 | | Interval Bottom: | 17662 ft. | Hole Size: | 0.36 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 19862 |
| Total Gas Produced (MCF) | 345957 |
| GOR | 17418 |
| GOR Determination | MCFE |
| Average BOE per Day | 217.799 |
| Average MCFE per Day | 1263.218 |
| Federal Financial Assurance | i | |
|
|
