COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-39885		Well Classification: N/AStatus: PA - 10/24/2014
Well Name/No:Horsetail #19N-1924M
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:WHITING OIL & GAS CORPORATION - 96155
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date10/24/2014
FacilityID:438120LocationID:438078
County:WELD #123Location:SWSE 19 10N57W 6
Field:WILDCAT - #99999Elevation:4748 ft.
Basin:DENVER (DJ) BASIN
Planned Location:660FSL  2656 FELLat/Long: 40.818861 / -103.794250Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.818860 / -103.794243Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: PA - 10/24/2014             Measured TD: 9370 ft.

 Wellbore Data for Original WellboreWellbore Classification:         PA - 10/24/2014
Wellbore PermitDRIFTED
Permit #: Expiration Date:7/13/2016
Proposed Depth/Form:9300 ft.
Surface Mineral Owner Same:Not available
Mineral Owner:Not availableSurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: ENRD , Formation: ENTRADA , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: LYNS , Formation: LYONS , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: MSSR , Formation: MISSOURI , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: PCMB , Formation: PRECAMBRIAN , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: WFCMP , Formation: WOLFCAMP , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: CONDUCTOR, Hole Size: 28 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED
Cement:Sacks: 179, Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 693, Top: 0 ft., Bottom: 1500 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 9300 ft., Weight: 29 , Citings Type: PLANNED
Cement:Sacks: 1054, Top: 0 ft., Bottom: 9300 ft.
Wellbore Completed
Completion Date:8/20/2014
Spud Date:8/3/2014Spud Date Is:ACTUAL
Measured TD:9370 ft.Measured PB depth:9370 ft.
True Vertical TD:True Vertical PB depth:
Log Types:LWD, MUD, CBL, Gamm Ray-CCL log, Compensated Neutron, Induction, Micro log, Triple Combination logs, Monopole Sonic.
Casing:String Type: CONDUCTOR, Hole Size: , Size: , Top: 0 ft., Depth: 109 ft., Weight: 42.09 , Citings Type: ACTUAL
Cement:Sacks: 0, Top: 0 ft., Bottom: 109 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1564 ft., Weight: 36.00 , Citings Type: ACTUAL
Cement:Sacks: 665, Top: 0 ft., Bottom: 1564 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: , Top: 0 ft., Depth: 9328 ft., Weight: 29.00 , Citings Type: ACTUAL
Cement:Sacks: 1390, Top: 9070 ft., Bottom: 9328 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PIERRE1514 ft.NN
HYGIENE3319 ft.NN
SHARON SPRINGS5494 ft.YN
NIOBRARA5500 ft.YN
FORT HAYS5784 ft.NN
CODELL5825 ft.NN
CARLILE5835 ft.NN
GREENHORN5957 ft.NN
GRANEROS6002 ft.NN
X BENTONITE6188 ft.NN
D SAND6297 ft.NN
HUNTSMAN6335 ft.NN
J SAND6397 ft.NN
SKULL CREEK6461 ft.NN
LAKOTA6625 ft.NN
MORRISON6756 ft.NN
SUNDANCE7028 ft.NN
ENTRADA7061 ft.NN
PERMIAN7079 ft.NN
LYONS7451 ft.NN
WOLFCAMP7764 ft.NN
AMAZON7918 ft.NN
NEVA8029 ft.NN
ADMIRE8096 ft.NN
PENNSYLVANIAN8197 ft.NN
VIRGIL8205 ft.NN
MISSOURI8292 ft.NN
MARMATON8594 ft.NN
FORT SCOTT8612 ft.NN
CHEROKEE8663 ft.NN
ATOKA8817 ft.NN
MORROW8988 ft.NN
MISSISSIPPIAN9154 ft.NN
PRECAMBRIAN9220 ft.NN
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY10/24/2014
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
November 2024 - October 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
