Wellbore #00 Wellbore Classification: OW Status: PR - 2/20/2016 Measured TD: 13379 ft. Vertical TD: 7280 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 2/20/2016 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 6/7/2016 | | Proposed Top PZ Location: | Sec:18 Twp: 1N 65W | Footage: 75 FNL 2618 FWL | | Bottom Hole Location: | Sec:6 Twp: 1N 65W | Footage: 410 FSL 2614 FEL | | Proposed Depth/Form: | 12859 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 480, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1540 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 580, Top: 0 ft., Bottom: 1540 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7666 ft., Weight: 26 , Citings Type: PLANNED | | Cement: | Sacks: 770, Top: 0 ft., Bottom: 7666 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6668 ft., Depth: 13281 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 2/11/2015 | | Spud Date: | 10/6/2014 | Spud Date Is: | ACTUAL | | Measured TD: | 13379 ft. | Measured PB depth: | 13327 ft. | | True Vertical TD: | 7280 ft. | True Vertical PB depth: | 7278 ft. | | Top PZ Location: | Sec:18 Twp: 1N 65W | Footage: 75 FNL 2618 FWL | | Bottom Hole Location: | Sec:6 Twp: 1N 65W | Footage: 410 FSL 2614 FEL | | Log Types: | CBL, LWD, (RESISTIVITY in 123-39593) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1606 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 641, Top: 0 ft., Bottom: 1606 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7574 ft., Weight: 26 , Citings Type: ACTUAL | | Cement: | Sacks: 704, Top: 36 ft., Bottom: 7574 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6750 ft., Depth: 13375 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 350, Top: 6818 ft., Bottom: 13375 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4561 ft. | | | | | SHARON SPRINGS | 7240 ft. | | | | | NIOBRARA | 7270 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 2/20/2016 Interval Top: 7606 ft. Interval Bottom: 13295 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 2/12/2016 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 1/30/2016 | Treatment End Date: | 2/7/2016 | | Treatment Summary: | "PERF AND FRAC FROM 7606-13,295.
309 BBL ACID, 210,475 BBL SLICKWATER, 4,422 BBL WATER, - 215,207 BBL TOTAL FLUID
6,219,722# 40/70 GENOA/SAND HILLS, - 6,219,722# TOTAL SAND."
| | Total fluid used in treatment (bbls): | 215207 | Max pressure during treatment (psi): | 7842 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 29 | | Total acid used in treatment (bbls): | 309 | Min frac gradient (psi/ft): | 0.91 | | Recycled water used in treatment (bbls): | 1650 | Total flowback volume recovered (bbls): | 2852 | | Fresh water used in treatment (bbls): | 213247 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 6219722 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/20/2016 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 419 | | BBLS_OIL | 76 | | BTU_GAS | 1369 | | CALC_BBLS_H2O | 419 | | CALC_BBLS_OIL | 76 | | CALC_GOR | 1105 | | CALC_MCF_GAS | 84 | | CASING_PRESS | 1550 | | GRAVITY_OIL | 47 | | MCF_GAS | 84 |
| | Perforation Data: | | Interval Top: | 7606 ft. | # Of Holes: | 696 | | Interval Bottom: | 13295 ft. | Hole Size: | 0.46 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1508 |
| Total Gas Produced (MCF) | 36018 |
| GOR | 23884 |
| GOR Determination | MCFE |
| Average BOE per Day | 21.120 |
| Average MCFE per Day | 122.498 |
| Federal Financial Assurance | i | |
|
|
