Wellbore #00 Wellbore Classification: OW Status: AB - 10/24/2024 Measured TD: 17143 ft. Vertical TD: 7561 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW AB - 10/24/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 5/14/2016 | | Proposed Top PZ Location: | Sec:31 Twp: 1N 67W | Footage: 1407 FSL 2391 FEL | | Bottom Hole Location: | Sec:30 Twp: 1N 67W | Footage: 1 FNL 2310 FEL | | Proposed Depth/Form: | 17143 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 720, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1265 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 480, Top: 0 ft., Bottom: 1265 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7987 ft., Weight: 26 , Citings Type: PLANNED | | Cement: | Sacks: 840, Top: 0 ft., Bottom: 7987 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6984 ft., Depth: 17143 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 11/29/2014 | | Spud Date: | 8/1/2014 | Spud Date Is: | ACTUAL | | Measured TD: | 17143 ft. | Measured PB depth: | 17087 ft. | | True Vertical TD: | 7561 ft. | True Vertical PB depth: | 7561 ft. | | Top PZ Location: | Sec:30 Twp: 1N 67W | Footage: 323 FNL 2296 FEL | | Bottom Hole Location: | Sec:30 Twp: 1N 67W | Footage: 26 FNL 2297 FEL | | Log Types: | CBL, MWD/LWD, (MWD/LWD with RESISTIVITY in API# 05-123-39427) | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1321 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 550, Top: 0 ft., Bottom: 1321 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: , Top: 0 ft., Depth: 7945 ft., Weight: 26 , Citings Type: ACTUAL | | Cement: | Sacks: 780, Top: 34 ft., Bottom: 7945 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6975 ft., Depth: 17133 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 675, Top: 6975 ft., Bottom: 17143 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 5094 ft. | | | | | SHARON SPRINGS | 7412 ft. | | | | | NIOBRARA | 7438 ft. | | | |
Formation NBRR Formation Classification: OW Status: AB - 10/24/2024 Interval Top: 16864 ft. Interval Bottom: 17015 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 4/23/2015 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 3/13/2015 | Treatment End Date: | 3/13/2015 | | Treatment Summary: | "PERF AND FRAC FROM 16864-17,015
12 BBL ACID ,6,533 BBL SLICKWATER, - 6,545 BBL TOTAL FLUID
183,984# 40/70 GENOA/SAND HILLS, - 183,984# TOTAL SAND
| | Total fluid used in treatment (bbls): | 6545 | Max pressure during treatment (psi): | 6236 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 1 | | Total acid used in treatment (bbls): | 12 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 2471 | | Fresh water used in treatment (bbls): | 6533 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 183984 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 5/6/2015 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 126 | | BBLS_OIL | 193 | | BTU_GAS | 1344 | | CALC_BBLS_H2O | 126 | | CALC_BBLS_OIL | 193 | | CALC_GOR | 1720 | | CALC_MCF_GAS | 332 | | CASING_PRESS | 850 | | GRAVITY_OIL | 46 | | MCF_GAS | 332 |
| | Perforation Data: | | Interval Top: | 16864 ft. | # Of Holes: | 48 | | Interval Bottom: | 17015 ft. | Hole Size: | 0.37 in. |
|
|
|
|
|
|
|
| Reported Plugged | Y | 10/24/2024 |
| Out Of Service Repurposed | N | |
| Out Of Service | Y | Plugging Due Date
12/31/2029 |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 0 |
| Total Gas Produced (MCF) | 0 |
| GOR | |
| GOR Determination | |
| Average BOE per Day | 0.000 |
| Average MCFE per Day | 0.000 |
| Federal Financial Assurance | i | |
|
|
