Wellbore #00 Wellbore Classification: OW Status: AB - 5/10/2017 Measured TD: 6550 ft. Vertical TD: 6493 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW AB - 5/10/2017 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 6/28/2018 | | Proposed Top PZ Location: | Sec:29 Twp: 10N 57W | Footage: 2462 FSL 2077 FEL | | Bottom Hole Location: | Sec:29 Twp: 10N 57W | Footage: 2246 FSL 2077 FEL | | Proposed Depth/Form: | 13846 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-695 , Unit Acreage: 960, Drill Unit: N/2 S29, All S20 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 80 ft., Weight: 92 , Citings Type: PLANNED | | Cement: | Sacks: 179, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 667, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13846 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 2310, Top: 0 ft., Bottom: 13846 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6 in., Size: 4.5 in., Top: 4958 ft., Depth: 13080 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 559, Top: 4958 ft., Bottom: 13080 ft. | | Casing: | String Type: OPEN HOLE, Hole Size: 8.75 in., Size: , Top: 0 ft., Depth: 6550 ft., Weight: , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 3/30/2017 | | Spud Date: | 3/30/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 6550 ft. | Measured PB depth: | 6550 ft. | | True Vertical TD: | 6493 ft. | True Vertical PB depth: | 6493 ft. | | Bottom Hole Location: | Sec:29 Twp: 10N 57W | Footage: 2232 FNL 2063 FEL | | Log Types: | Mud log, MWD/LWD, CAL, IND, NEU, Triple Combo | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 101 ft., Weight: 75 , Citings Type: ACTUAL | | Cement: | Sacks: 153, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2043 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 615, Top: 0 ft., Bottom: 2043 ft., Determination Method: VISU | | Casing: | String Type: OPEN HOLE, Hole Size: 8.75 in., Size: , Top: 2043 ft., Depth: 6550 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: , Top: , Bottom: , Determination Method: | | Additional Cement: | String Type: OPEN HOLE , Top: 5035 ft., Depth: 5035 ft., Bottom: 6464 ft., Sacks: 575, Method: | | Formation | Interval Top | Log Bottom | Cored | DSTs | | CARLILE | | | Z | N | | CODELL | | | Z | N | | FORT HAYS | | | Z | N | | NIOBRARA | | | Z | N | | SHARON SPRINGS | | | N | N | | PIERRE | 1426 ft. | | N | N | | HYGIENE | 3159 ft. | | N | N | | GRANEROS | 5909 ft. | | Z | N | | D SAND | 6209 ft. | | Z | N | | HUNTSMAN | 6244 ft. | | Z | N | | MOWRY | 6285 ft. | | Z | N | | DAKOTA-JSND | 6309 ft. | | Z | N | | SKULL CREEK | 6365 ft. | | Z | N | | No formation data to display. |
Sidetrack #01 Wellbore Classification: OW Status: PR - 6/23/2017 Measured TD: 13807 ft. Vertical TD: 5725 ft.| Wellbore Data for Sidetrack #01 | Wellbore Classification: OW PR - 6/23/2017 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 10/23/2018 | | Proposed Top PZ Location: | Sec:29 Twp: 10N 57W | Footage: 2550 FNL 2077 FEL | | Bottom Hole Location: | Sec:20 Twp: 10N 57W | Footage: 100 FNL 1980 FEL | | Proposed Depth/Form: | 13846 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NB-CD , Formation: NIOBRARA-CODELL , Order: 535-695 , Unit Acreage: 960, Drill Unit: N/2 S29, All S20 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 20 in., Top: 0 ft., Depth: 80 ft., Weight: 92 , Citings Type: PLANNED | | Cement: | Sacks: 179, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 667, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 6084 ft., Weight: 29 , Citings Type: PLANNED | | Cement: | Sacks: 408, Top: 0 ft., Bottom: 6084 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6 in., Size: 4.5 in., Top: 5265 ft., Depth: 13846 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 591, Top: 5265 ft., Bottom: 13846 ft. |
| | |
| Wellbore Completed | | Completion Date: | 4/15/2017 | | Spud Date: | 3/30/2017 | Spud Date Is: | ACTUAL | | Measured TD: | 13807 ft. | Measured PB depth: | 13761 ft. | | True Vertical TD: | 5725 ft. | True Vertical PB depth: | 5724 ft. | | Top PZ Location: | Sec:29 Twp: 10N 57W | Footage: 2350 FNL 2050 FEL | | Bottom Hole Location: | Sec:20 Twp: 10N 57W | Footage: 100 FNL 2011 FEL | | Log Types: | Mud log, MWD/LWD, CBL (CAL, IND, NEU, Triple Combo in 123-38807-00) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 101 ft., Weight: 75 , Citings Type: ACTUAL | | Cement: | Sacks: 153, Top: 0 ft., Bottom: 101 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2043 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 615, Top: 0 ft., Bottom: 2043 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 6164 ft., Weight: 29 , Citings Type: ACTUAL | | Cement: | Sacks: 640, Top: 1108 ft., Bottom: 6164 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 4882 ft., Depth: 13807 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 645, Top: 4882 ft., Bottom: 13807 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SHARON SPRINGS | 5403 ft. | | N | N | | NIOBRARA | 5406 ft. | | N | N | | FORT HAYS | 5690 ft. | | N | N | | CODELL | 5731 ft. | | N | N | | CARLILE | 5741 ft. | | N | N |
Formation FTHYS Formation Classification: OW Status: CM - 6/8/2018 Interval Top: 7689 ft. Interval Bottom: 9191 ft.| Completed Information for Formation FORT HAYS | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | FORT HAYS | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 6/8/2018 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 7689'-7901' (30 shots); 8469'-9191' (90 shots) | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation FTHYS. |
| | Perforation Data: | | Interval Top: | 7689 ft. | # Of Holes: | 120 | | Interval Bottom: | 9191 ft. | Hole Size: | |
|
Formation CODL Formation Classification: OW Status: CM - 6/8/2018 Interval Top: 6528 ft. Interval Bottom: 13719 ft.| Completed Information for Formation CODELL | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CODELL | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 6/8/2018 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 6528'-6990' (60 shots); 7270'-7542' (40 shots); 8004'-8380' (60 shots); 9269'-13719' (579 shots) | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CODL. |
| | Perforation Data: | | Interval Top: | 6528 ft. | # Of Holes: | 739 | | Interval Bottom: | 13719 ft. | Hole Size: | |
|
Formation CARL Formation Classification: OW Status: CM - 6/8/2018 Interval Top: 6240 ft. Interval Bottom: 7186 ft.| Completed Information for Formation CARLILE | | 1st Production Date: | N/A | Choke Size: | | | Formation Name: | CARLILE | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | | | Treatment Date: | 6/8/2018 | Treatment End Date: | N/A | | Treatment Summary: | Completed Depths: 6240'-6446' (30 shots); 7080'-7186' (20 shots) | | Total fluid used in treatment (bbls): | | Max pressure during treatment (psi): | | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | | | Type Of gas: | | Number Of staged intervals: | | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | | | Total proppant used (lbs): | | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | No Initial Test Data was found for formation CARL. |
| | Perforation Data: | | Interval Top: | 6240 ft. | # Of Holes: | 50 | | Interval Bottom: | 7186 ft. | Hole Size: | |
|
Formation CLCDFH Formation Classification: OW Status: PR - 6/23/2017 Interval Top: 6240 ft. Interval Bottom: 13719 ft.| Completed Information for Formation CARLILE-CODELL-FORT HAYS | | 1st Production Date: | 6/11/2017 | Choke Size: | 0.000 in. | | Formation Name: | CARLILE-CODELL-FORT HAYS | Commingled: | Yes | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 5/1/2017 | Treatment End Date: | 5/6/2017 | | Treatment Summary: | 30 Stage Plug & Perf 920940# 100 Mesh, 4064584# Premium White, 30/50, 357 bbls15% HCl, 193605 bbls slickwater
Top of producing zone corrected to 2466 FNL 436 FWL based on top perforation at 6240'. | | Total fluid used in treatment (bbls): | 193962 | Max pressure during treatment (psi): | 7504 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 30 | | Total acid used in treatment (bbls): | 357 | Min frac gradient (psi/ft): | 0.80 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 8055 | | Fresh water used in treatment (bbls): | 193605 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 4985524 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 4853 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 6/23/2017 | Test Method: | Separator | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 377 | | BBLS_OIL | 191 | | BTU_GAS | 1303 | | CALC_BBLS_H2O | 377 | | CALC_BBLS_OIL | 191 | | CALC_GOR | 518 | | CALC_MCF_GAS | 99 | | CASING_PRESS | 700 | | GRAVITY_OIL | 36 | | MCF_GAS | 99 | | TUBING_PRESS | 200 |
| | Perforation Data: | | Interval Top: | 6240 ft. | # Of Holes: | 909 | | Interval Bottom: | 13719 ft. | Hole Size: | 0.375 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 3183 |
| Total Gas Produced (MCF) | 8038 |
| GOR | 2525 |
| GOR Determination | BOE |
| Average BOE per Day | 12.490 |
| Average MCFE per Day | 72.442 |
| Federal Financial Assurance | i | |
|
|
