Wellbore #00 Wellbore Classification: OW Status: PR - 11/26/2014 Measured TD: 13750 ft. Vertical TD: 5599 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 11/26/2014 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/11/2015 | | Proposed Top PZ Location: | Sec:26 Twp: 10N 58W | Footage: 2179 FNL 637 FWL | | Bottom Hole Location: | Sec:23 Twp: 10N 58W | Footage: 100 FNL 825 FWL | | Proposed Depth/Form: | 13287 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 535-314 , Unit Acreage: 960, Drill Unit: N/2 26 all 23 | | Casing: | String Type: CONDUCTOR, Hole Size: 16.063 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 719, Top: 0 ft., Bottom: 1500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 5894 ft., Weight: 29 , Citings Type: PLANNED | | Cement: | Sacks: 413, Top: 0 ft., Bottom: 5894 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6 in., Size: 4.5 in., Top: 5112 ft., Depth: 13287 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 5/19/2014 | | Spud Date: | 5/9/2014 | Spud Date Is: | ACTUAL | | Measured TD: | 13750 ft. | Measured PB depth: | 13652 ft. | | True Vertical TD: | 5599 ft. | True Vertical PB depth: | 5605 ft. | | Top PZ Location: | Sec:26 Twp: 10N 58W | Footage: 2566 FNL 840 FWL | | Bottom Hole Location: | Sec:23 Twp: 10N 58W | Footage: 136 FNL 873 FWL | | Log Types: | MWD/LWD, Mud, CBL, TRIPLE COMBO IN 123-38339 | | Casing: | String Type: CONDUCTOR, Hole Size: 20 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 75 , Citings Type: ACTUAL | | Cement: | Sacks: , Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1517 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 719, Top: 0 ft., Bottom: 1517 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 5975 ft., Weight: 29 , Citings Type: ACTUAL | | Cement: | Sacks: 411, Top: 0 ft., Bottom: 5975 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6 in., Size: 4.5 in., Top: 4863 ft., Depth: 13745 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 670, Top: 4863 ft., Bottom: 13745 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PIERRE | 1691 ft. | | N | N | | HYGIENE | 3513 ft. | | N | N | | SHARON SPRINGS | 5764 ft. | | N | N | | NIOBRARA | 5777 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 11/26/2014 Interval Top: 6070 ft. Interval Bottom: 13578 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 10/20/2014 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 9/5/2014 | Treatment End Date: | 9/14/2014 | | Treatment Summary: | 40-stage Frac: 81382 bbls ClearStar XL Gel; 18264 bbls Linear Gel; 5791333# 20/40 Wh snd, 109422# 40/70 Wh snd, 1003 bbls 15% HCl, 32704 bbls Slickwater. | | Total fluid used in treatment (bbls): | 133353 | Max pressure during treatment (psi): | 8429 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 40 | | Total acid used in treatment (bbls): | 1003 | Min frac gradient (psi/ft): | 0.80 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 12638 | | Fresh water used in treatment (bbls): | 132350 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 5900755 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.875 in. | Tubing Setting Depth: | 5570 ft. | | Tubing Packer Depth: | 5570 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/26/2014 | Test Method: | Separator | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 185 | | BBLS_OIL | 259 | | BTU_GAS | 1424 | | CALC_BBLS_H2O | 185 | | CALC_BBLS_OIL | 259 | | CALC_GOR | 290 | | CALC_MCF_GAS | 75 | | CASING_PRESS | 900 | | GRAVITY_OIL | 35 | | MCF_GAS | 75 | | TUBING_PRESS | 400 |
| | Perforation Data: | | Interval Top: | 6070 ft. | # Of Holes: | 1440 | | Interval Bottom: | 13578 ft. | Hole Size: | 0.375 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1907 |
| Total Gas Produced (MCF) | 4040 |
| GOR | 2118 |
| GOR Determination | BOE |
| Average BOE per Day | 7.216 |
| Average MCFE per Day | 41.863 |
| Federal Financial Assurance | i | |
|
|
