Wellbore #00 Wellbore Classification: OW Status: PR - 7/15/2022 Measured TD: 13307 ft. Vertical TD: 7191 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 7/15/2022 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 7/2/2015 | | Proposed Top PZ Location: | Sec:14 Twp: 2N 68W | Footage: 868 FNL 439 FWL | | Bottom Hole Location: | Sec:11 Twp: 2N 68W | Footage: 460 FNL 400 FWL | | Proposed Depth/Form: | 13388 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 400, Drill Unit: GWA | | Casing: | String Type: CONDUCTOR, Hole Size: 22 in., Size: 16 in., Top: 0 ft., Depth: 80 ft., Weight: 30 , Citings Type: PLANNED | | Cement: | Sacks: 80, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 800 ft., Weight: 40 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 800 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7868 ft., Weight: 26 , Citings Type: PLANNED | | Cement: | Sacks: 446, Top: 500 ft., Bottom: 7868 ft. | | Casing: | String Type: 2ND, Hole Size: 6.125 in., Size: 4.5 in., Top: 0 ft., Depth: 13388 ft., Weight: 13.5 , Citings Type: PLANNED | | Cement: | Sacks: 222, Top: 7568 ft., Bottom: 13388 ft. |
| | |
| Wellbore Completed | | Completion Date: | 11/2/2014 | | Spud Date: | 10/20/2014 | Spud Date Is: | ACTUAL | | Measured TD: | 13307 ft. | Measured PB depth: | 13236 ft. | | True Vertical TD: | 7191 ft. | True Vertical PB depth: | 7191 ft. | | Top PZ Location: | Sec:14 Twp: 2N 68W | Footage: 722 FNL 473 FWL | | Bottom Hole Location: | Sec:11 Twp: 2N 68W | Footage: 500 FNL 398 FWL | | Log Types: | CBL, MWD, (Induction 123-10228) | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 16 in., Top: 0 ft., Depth: 109 ft., Weight: 65 , Citings Type: ACTUAL | | Cement: | Sacks: 170, Top: 0 ft., Bottom: 109 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 914 ft., Weight: 40 , Citings Type: ACTUAL | | Cement: | Sacks: 370, Top: 0 ft., Bottom: 929 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7777 ft., Weight: 26 , Citings Type: ACTUAL | | Cement: | Sacks: 710, Top: 595 ft., Bottom: 7790 ft., Determination Method: CBL | | Casing: | String Type: 2ND, Hole Size: 6.125 in., Size: 4.5 in., Top: 0 ft., Depth: 13287 ft., Weight: 13.5 , Citings Type: ACTUAL | | Cement: | Sacks: 504, Top: 5769 ft., Bottom: 13307 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SHARON SPRINGS | 7269 ft. | | | | | NIOBRARA | 7448 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 12/1/2019 Interval Top: 7802 ft. Interval Bottom: 13233 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 7/17/2015 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 2/13/2015 | Treatment End Date: | 2/18/2015 | | Treatment Summary: | Stages 1 - 35 treated with a total of 98,756 bbls of fresh water, 390 bbls of recycled water, 488 bbls of acid 15%, 494 bbls of additives, and 6,286,508 lbs of 40/70 Sand Proppant | | Total fluid used in treatment (bbls): | 100128 | Max pressure during treatment (psi): | 9414 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 35 | | Total acid used in treatment (bbls): | 488 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | 390 | Total flowback volume recovered (bbls): | 390 | | Fresh water used in treatment (bbls): | 99250 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 6286508 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7343 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 7/25/2015 | Test Method: | FLOWS FROM WELL | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_OIL | 482 | | BTU_GAS | 1298 | | CALC_BBLS_OIL | 482 | | CALC_GOR | 1249 | | CALC_MCF_GAS | 602 | | CASING_PRESS | 2384 | | GRAVITY_OIL | 50 | | MCF_GAS | 602 | | TUBING_PRESS | 1592 |
| | Perforation Data: | | Interval Top: | 7802 ft. | # Of Holes: | 867 | | Interval Bottom: | 13233 ft. | Hole Size: | 0.44 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 1403 |
| Total Gas Produced (MCF) | 41867 |
| GOR | 29841 |
| GOR Determination | MCFE |
| Average BOE per Day | 23.643 |
| Average MCFE per Day | 137.121 |
| Federal Financial Assurance | i | |
|
|
